DIGITAL UV SENSOR FOR MOBILE, WEARABLE, AND IOT APPLICATIONS (GUVA-C32SM)

         DIGITAL UV SENSOR FOR MOBILE, WEARABLE, AND IOT APPLICATIONS                                                            Model Number:  GUVA-C32SM                                              1.Features - Integrated GaN Sensors for UVA
   in a single package
- UV index measurement supported(1…>14)
- Programmable Gain and Integration time
- I2C slave interface up to 400KHz
- Power management modes
- Shutdown current : 0.8uA typical
- Supply voltage of 2.6V to 3.6V
- 2.0mm×2.3mm×1.4mm 4-pin OLGA package   2.Applications Smartphone, Watch, Weather station,
Bicycle Navigation, Gaming, Accessary   3.General Description GUVA-C32SM supports integrated functions of an ultraviolet light sensor such that can be easily configured and used in user applications. This device has photodiodes, amplifiers, ADC, digital control logic and I2 C interface circuit to measure the volumes of UVA. The GUVA-C32M can acquire the intensity of UVA, respectively and outputs digital count according to
the each intensity. By using power management mode properly according to the work to be done,
the power consumption can be reduced.                              Functional Block Diagram       Lieen  Skype:isweek_lieenli Sale Dep.Shenzhen Week Technology Ltd Tel:  +86-755-83289036  Ext.817 Fax:  +86-755-83289053  www.isweek.com
