UV Flame Detection Sensor UV Sensor with High Sensitivy SG01D-5LENS

    UV Flame Detection Sensor UV Sensor  with High Sensitivy SG01D-5LENS                                                           Avirtual = 11,0 mm2                                                              Properties of the SG01D–5LENS UV photodiode
• Broadband UVA+UVB+UVC, PTB reported high chip stability, for flame detection
• Radiation sensitive area A = 11,0 mm2
• TO5 hermetically sealed metal housing with concentrator lens, 1 isolated pin and 1 case pin
• 10μW/cm2 peak radiation results a current of approx. 350 nA   About the material Silicon Carbide (SiC)
SiC provides the unique property of extreme radiation hardness, near-perfect visible blindness, low dark current, high speed and low noise. These features make SiC the best available material for visible blind semiconductor UV detectors. The SiC detectors can be permanently operated at up to 170°C (338°F). The temperature coefficient of signal responsivity) is also low, < 0,1%/K. Because of the low noise (dark current in the fA range), very low UV radiation intensities can be measured reliably. Please note that this device needs an appropriate amplifier (see typical circuit on page 3).
Options
SiC photodiodes are available with seven different active chip areas from 0,06 mm2 up to 36 mm2. Standard versionis broadband UVA-UVB-UVC. Four filtered versions lead to a tighter sensitivity range. All photodiodes have a hermetically sealed metal housing (TO type), either a 5,5 mm diameter TO18 housing or a 9,2 mm TO5 housing. Further option is either a 2 pin header (1 isolated, 1 grounded) or a 3 pin header (2 isolated, 1 grounded).     Contact :
