POM Sheet (Black or white)

POM SHEET(BLACK OR WHITE)   POM (Full-name: Polyformaldehyde) is a engineering plastics of non-side-chain, high density, high crystalline and linear polymer, which is praised Plastic Steel, and has comprehensive excellent performances, such as: wear-resistance, high hardness, anti-impregnant, good rigidity (Tensile modulus of elasticity), chemical stability, isolation resistance and dimensional stability. POM has widely applied in Automobile industries, electronic and electric products, commodity, pipeline & fittings, exact apparatus and so on, which can be instead of the bronze, Zinc, tin and other metals.
Except POM-H, is often copolymerized with ethylene oxide together, in order to avoid the melting of POM material in the high temperature. POM-H has the better performances than POM-C in its high crystalline, mechanical strength and rigidity. And POM-C has the better performances than POM-H in its low melting point, temperature stability, fluxion characteristic and machining capability.
Automobile industries: POM has a large application in car industries, because the mechanical parts made by POM, which has the advantages of high mechanical strength, high hardness, good wear-resistance, low co-efficient of friction, easy to maintain, reducing cost and so on, can be used in cars instead of coppery half stalk and planet gear. It not only saving copper materials, but also improving service life. At the engine fuel system, components for hose valves and case cover of radiator, cooling fluid's standby case, water valve, oil box' cover, pump impeller, shell of gasification machine and accelerator pedal and so on.
Electronic and electric Industries: because of its lower power consuming, high dielectric strength and insulation resistance and electronic arc resistance,  POM has widely applied in electronic and electric Industries, such as: shell of electronic spanner, shell of electronic scissors, shell of coal drilling machine ,handle of switch, parts also for phone, wireless recorder, video tape recorder, television, computer, electrograph, calculagraph, bracket of recorder tape and so on.
Agricultural machine: part of manual sprayer, joint and transport part of seeder, parts of milk machine, shell of irrigation and drainage, valve, joint and bush of water and so on.
Other field:
Pharmacy & packing Machine: transporting screw, planet gear, gear bar, chain wheel and cushion bar and so on.
Construction industries: water tap, window frame, wash pot, water tank, pulley for portiere, shell of water meter and tie-in of water pipe.    POM C SHEET/DELRIN SHEET/ACETAL SHEET PROPERTIES

Content Features/Property	Testing Standard	Unit	POM(DELRIN)	POM-GF30	ESD      POM	Conductive POM
Long Term Working Temp.		°c	110	120	100	100
Density	ASTM D792	g/cm3	1.4~1.45	1.56	1.32	1.41
Yield Stretch Strength	ASTM D638	MPa	60.3	80	70	69
Breaking Stretch Strength	ASTM D638	MPa	65	55	63	63
Breaking Stretch Rate	ASTM D638	%	25	10	22	22
Bending Modulus	ASTM D790	MPa	2.57	2.3	3	2.8
Hardness	Shore type D	MPa	84	85	81	80
Impact Strength	ASTM D256	KJ/m2	74	40	50	50

   POM C SHEET/DELRIN SHEET/ACETAL SHEET Specification:

Delrin POM SHEET ROD COLOR	Delrin POM SHEET SIZE	Delrin POM ROD SIZE
BLACK	(6~200)*620*1230MM	(6~200)*1000MM
WHITE	(6~200)*1000*2000MM	(6~200)*2000MM
