GreenTouch wholesale alibaba china 21.5" Open Frame touch screen monitor compatible with ELO,3M

GreenTouch wholesale alibaba china 21.5" Open Frame touch screen monitor compatible with ELO,3M Professional Website: https://www.greentouch.com.cn or Click Here. Tel/Wechat: +86 013827465009,TM : keetouch , Skype: greentouch5                                        GreenTouch Open frame touch screen monitor   Product Overviews GreenTouch elo open frame touch screen monitor adopt new A+LCD screen produced by international companies,designed with all-plastic ergonomic shell,and new energy saving drive board,special for desktop and desktop public service inquiry syestem,POS systems,hotel recept-service,industrial manufacturing,infromation systems and other interactive touch applications environmental design   GT-TM021501 elo Open frame touch screen monitor use Infrared(Multi-touch) and SAW (waterproof,dustproof,vandalproof) touch screen that independently developed and produced by our company,it has a high-quality ,cost effective,good durabilityy,and stability character.pure glass for touch screen also provides good clarity and light transmittance.open frame touch monitor,rational constructure,and provide convenience way of the installed and fixed way.this kind of the open bracket are very goodfor Kiosk,touch terminal etc.     Advantages 1.Touch function and LCD display all in one solution, performance excellent, good appearance; 2.Higher sensitivity and response speed than same product, very smoothly when touch and draw line; 3.Built-in RS232 & USB 2kinds interfaces,Mood interfaces of RS232 and USB can be selected by customer ; 4.High life time, LCD upgrade or change will not cause the touch monitor appearance different; 5.Hight brightness, high contrast ratio, quick response time, multi color support, wide viewing angle; 6.National standard professional production line, one million dust-free environment ,screen body and LCD screen fit; 7.Removeable External mounting bracket and National standard VESA install holes; 8.Certification: FCC,CE,CCC,UL; 9.Accept customization     Specification

Model Number	GT-TMO215001
Name	21.5"Open Frame touch monitor
Structure	Open frame iron box, black color in front ,white sliver on the back
Display Type	Full New 21.5"Active matrix TFT-LCD 16:9
Active area	477(H)×268(V)
Resolution	1920×1080@60Hz
Support color	16.7M
Brightness (Typ.)	Display Panel :250cd/m2(Typ.)
	After Add the touch screen :230cd/m2(Typ.)
Response time (Typ.)	16ms(Typ.)
Pixel	0.297*0.297mm
Viewing Angle(Typ.at CR>10))	Horizontal(L/R):75°/75°
	Vertical(Up/Down):65°/65°
Contract (Typ.)	450:1(Typ.)
Video input	Mini D-Sub15pin VGA,DVI
Scan Frequency(L/F)	Horizontal:30~80KHz ,vertical: 56.3~75Hz
Power Input	External connect power adapter,Support AC 100 ~ 240V,50 ~ 60Hz,DC12V-3A
Environment	Operate temperature :0 ~ 50°C
	Storage temperature :-20 ~ 60°C
	Operating humidity:20% ~ 80%
	Storage humidity:10% ~ 90%
Mean Time Between Failure (MTBF)	30,000 hours
Backlight working life(Typ.)	50,000 hours
Power consumption	max19W
OSD Control	Button :POWER,MENU,AUTO,UP,DOWN
Installation method	Install 75*75 mm & 100*100mm VESA hole on the back,aside hole also can be used
Touch screen Type	SAW,IR touch screen can be selected
Touch life	Over 5,00 million times
Surface hardness of the touch screen	Equal with glass,7mosh
Touch object	Finger or touch pen
Touch screen interface	USB or RS232 interface
Touch screen response time	8ms
Touch force	30g
Certification	FCC,CE,CCC,RoHS
Warranty	Display panel 1yesrs,touch screen 1year
Note: LCD display parameter will be changed according to the LCD brand and model

  Accessories

Power cable(1pcs)	VGA cable(1pcs)	Windows 2000
Power adapter(1pcs)	Driver CD(1pcs)	Windows XP
RS232 or USB wire(1pcs)	Mounting bracket(1pcs)	Linux
	Mounting screw(4pcs)	Windows7
		Windows VISTA

    Finished Products       Certifications          Related Products of ours :   Please Click here to know more touch products which may interested by you and contact us, Thank you for your concern !     FAQ Q: What system it support ? A: compatible with  Windows, Android, Linux , ELO, 3M.
  Q: Does the touch monitor support 3M and ELO ? A: Yes, our SAW touch screen support ELO                    Infrared touch screen support 3M    Q: What is your MOQ? A: 1pcs   Q: Which certificates passed ?  A: CE,FCC,RoHs.   Q: How proceed the order?
A: online or offline     Payment terms: TT, Western Union, PAYPAL, Trade Assurance
   1) For sample order : 100% T/T, Western Union, Paypal.
   2) For bulk order more than ten thousand dorllors : 50% Deposit T/T Blance before goods ship out.   Q: What is your guarantee period?
A:  1years warranty.   Q: What is your delievey time ? A: Sample order : within 1-3days, 5-12working days for bulk production after confirmed.   Q: How to ship it out ?
A: Use express : DHL, FEDEX,TNT,EMS or UPS.
  Q: what's the direct contact way ?  A: Skype: greentouch5     Tel/Wechat : +86 13827465009     or send inquiry through email or just click below " send " to send message to us. Hope to set up friendly business relationship with all of you.Your comments on our products and any information from your market will be highly appreciated.   (If I'm off line, would you send a massage to me or email please ? i will reply within 12hours .)
