UL LED Puck Light Cove Lighting LED

UL LED Puck Light Cove Lighting LED Product Description Features CLEDLIGHTL’s C09 LED puck light is widely used in showcases, display case or furniture. This LED
puck light is especially applied to noble product accent lighting.By using DC Receptacle, a few lamps can be
connected one by one quickly.   1.Energy saving up to 50% compared with traditional fluorescent under the same flux
2.Life Span–over 50,000 hours
3.Available in cool white neutral white and warm white color temperatures; Available in other colors
4.No harmful ultraviolet (UV) rays
5.Easy linking up to 24 watts per run 6.Easy installation using 1 M3 screws
7.Using low voltage, more safety   Specifications •Dimensions: 90mm (Diameter) x 8mm (height)
•Materials: Hard anode oxidation of Al alloy after machining, Acrylic Lens
•Light Source: High brightness 3528 SMD LED
•Operating Temperature: -20°C to 40°C - Indoors
•Warranty: 2 year with proper installation and power supply
•Installation: 1 M3.0 screws make it easy to install

Product	Diameter	Color	Number of leds	Voltage	LED Power	Radiance	Color Temp	Luminous Flux
	[mm]		[pcs]	[V DC]	[W]	Angle [°]	[K]	[lm]
C09	¢=90	white	42	12/24	3	90	2700-6500k	250

Power supply usage instruction The following table shows how many modules the power supply we provide can drive respectively. You can  select suitable power supply according to the power per run.

Power Supply	C09 LED puck light
6W	2 (with DC receptacle)
12W	4 (with 4 hole location DC receptacle)
24W	8 (with 8 hole location DC receptacle)

Note: You can choose different power supply and accessories according to the power supply usage  instruction.   Applications
LED show case lighting; LED shelf lighting; LED display case lighting; LED retail product Lighting; LED
Furniture Lighting; LED bookcase lighting; LED wardrobe lighting; LED wine cabinet lighting; LED under
cabinet lighting; LED kitchen cabinet lighting; LED cove lighting; LED accent lighting Safety Information 1) Indoor use only 2)LED Module incorporates no protection against short circuits, overload or overheating. Therefore it is  absolutely necessary to operate the modules with an electronically stabilised power supply offering protection against the above mentioned safety risks. Our power supply is specifically designed with protection features  for safe operation. When using power supply other than us, the following basic safety features are required,  in addition to any other application specific concerns and local safety codes: • Short circuit protection     • Overload protection     • Overheat protection Packaging & Shipping Package Contents

Product	Color box* size	Carton size	Units/carton
C09	100X100X30	320(length)X220(width)X420(height)	80
6w Power supply with connector cable	76X61X46	250(length)X170(width)X270(height)	40
12w Power supply with DC receptacle	136x58x77	315(length)X290(width)X340(height)	40
