800-2700MHz Broadband Indoor Wall Mounted Antennas

Specifications 1.Wall Mounted Antennas

2.Competive price

3.High performance

4.Signal amplify

5.OEM & ODM

800-2700MHz Broadband Indoor Wall Mounted Antennas                 Specification :

ELECTRICAL
MODEL	GA-XDQ800/2700-5
Frequency Range	806-960/1710-2700-MHz
Gain	3 / 5-dBi
Beamwidth	H:360-° E: 45-65-°
VSWR	≤ 1.5 / 1.8
Polarization	Vertical
Max power	50 -W
Nominal Impedance	50 -Ω
Lightning Protection	DC Ground
MECHANICAL
Connector­­­	N female or customized
Antenna Dimension	165*85-mm
Weight	0.35-kg
Radome Material	Waterproof ABS
Working Temperature-°C	-40~+60
Shipping Details
Packing QTY:	20pcs / Carton
Carton Size :	780*320*270mm
Package Weight	7kg

    Horizontal Beamwidth :     Vertical Beamwidth :       Introduction :   Gisantone has a top researching team, advanced testing equipment and powerful technical strength. We research, produce and sell VHF, UHF, CDMA, GSM, WCDMA, CDMA2000, TD-SCDMA, MIMO , WIFI, WLAN, WIMAX , 5.1G-5.8GHz , 4GHz LTE , directly repeater station, indoor coverage antennae, prettify antennae, wireless public telephone, various communicational antennae of any frequency from 88MHz to 6GHz .  Providing OEM & ODM serivces . If you have any needs, welcome to contact . We looking forward to hearing from any of your news .
