806-960/1710-2500-MHz CDMA GSM Indoor Wall Mount Antenna

Get Latest Price

Delivery Time:: 1 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

Specifications 1.Indoor Wall Mount Antenna

2.Competive price

3.High gain

4. Ceiling Antennas

5.Certification:ISO 9001:2008,Rohs,CNAS,CMA

806-960/1710-2500-MHz CDMA GSM Indoor Wall Mount Antenna

Specification :

ELECTRICAL
MODEL	GA-XDD800/2500-5/7
Frequency Range	806-960/1710-2500-MHz
Gain	5 / 7-dBi
Beamwidth	H:90-120-°E: 80-120-°
VSWR	≤1.5
Polarization	Vertical
Max power	100 -W
Nominal Impedance	50 -Ω
Lightning Protection	DC Ground
MECHANICAL
Connector	N female or customized
Antenna Dimension	187*86-mm
Weight	0.3-kg
Radome Material	Waterproof ABS
Rated Wind Velocity	60-m/s
Mounting Kits	Fixed with Nut
Shipping Details
Packing QTY:	20pcs / Carton
Carton Size :	780320270mm
Package Weight	7kg

Horizontal Beamwidth :

Vertical Beamwidth :

Introduction : Gisantone has a top researching team, advanced testing equipment and powerful technical strength. We research, produce and sell VHF, UHF, CDMA, GSM, WCDMA, CDMA2000, TD-SCDMA, MIMO , WIFI, WLAN, WIMAX , 5.1G-5.8GHz , 4GHz LTE , directly repeater station, indoor coverage antennae, prettify antennae, wireless public telephone, various communicational antennae of any frequency from 88MHz to 6GHz . Providing OEM & ODM serivces . If you have any needs, welcome to contact . We looking forward to hearing from any of your news .
Installation :
