Vehicle Loop Detector Vehicle Loop Detector Introduction   SFLP102/103 is used for wherever vehicles have to be detected, for example for monitoring and safe-guarding access ways or for counting vehicles. The output signal can be used for controlling door and gate drive mechanisms, operating barriers, controlling traffic light systems or activating card dispensers in parking lots. SFLP102/103 has two-way output relays. One is unlimited output when loop is temporarily covered, while the other is multi-mode that can be set by users.   SFLP102/103 has two-way output relays. One is unlimited output when loop is permanently covered,while the other is multi-mode that can be set by users.   Specifications Operating voltages:      12V AC/DC ±5% 24V AC/DC ±5% 110V AC ±10% 220V AC ±10% Power consumption:    < 5W Output:                          Relay output Frequency range:         20KHz to 170KHz (adjustable) Reaction time:               100 ms Sensitivity:                     high, medium, low (adjustable) Loop inductance:                Ideal  80µH to 300µH (include connecting wiring) Max  50µH to 500µH (include connecting wiring) Loop conn. Wiring:           max. 100m, twisted at least 20 times per meter, total resistance <10 Ohm Operating temp.:             -30°C to +70°C Storage temp.:                 -40°C to +85°C Connection:                      11-pin socket Dimensions:                     74×36×85 mm (L×W×H) Net Weight:                       270g (include socket) Single loop detectorSingle loop detectorSingle loop detectorSingle loop detectorSingle loop detectorSingle loop detectorSingle loop detectorSingle loop detectorSingle loop detectorSingle loop detectorSingle loop detectorSingle loop detectorSingle loop detectorSingle loop detector    Key words:  loop detector
