Motor Hybrid Card Reader and Writer CRT-350

Specifications *Motor Hybrid Card Reader and Writer CRT-350

*Support RS232 and USB

* IC/RFID/Magnetic card reading/writing

     Features:   3 in 1: IC/RFID/Magnetic card reading/writing in one. LoCo&HiCo options and operate LoCo&HiCo at the same time. Multiple card transportation: from front and rear. Reject abnormal card and extra long card. Two anti-skimming ways: software and hardware. Multiple kind of shutter: G, E, D kind of shutter. E-shutter has anti-fishing & anti-skimming functions. Optional components: Power-down protection plate and PASM board
(4 / 8 bits). Confirm to WOSA/XFS 2.0 and 3.0. SP provided. Multiple communication protocol choices Support RS232 and USB RoHS standard compliant.     Application:   ATM   kiosk   Security terminal   Access control terminal     Parking system       Motor Hybrid Card Reader and Writer CRT-350

Model	CRT-350
Features	EMV certified
	Magnetic/IC/RFID card read/write
	Lo-Co & Hi-Co encoding options
	SAM slot option
	Electric (Anti-theft) & security shutter options
	Insert& eject from front/rear side
Application	ATM
	Information kiosk
	Electronic purse
Specification
Card standard	IC Card :ISO7816 Magnetic Card:ISO7810 ID-1,7811 RFID Card:ISO14443 Type A / B
Weight	Approx. 1.8kg
Life	Magnetic head: 1,000,000 cycles min IC card Contact : 500,000 cycles min Gearing: 1,000,000 cycles min
Communication	RS-232/USB
Power supply	DC 24V +/-10%
Temperature/Humidity	Operation:0~50oC/0~90%RH(No condensing) Storage:-10~75oC/0~90%RH(No condensing)
Dimension	215x124x90mm
