3 inch dot matrix printer SP-T5

Specifications 1. RS232/Bluetooth

2. Support Symbian, Android, WinCE

3. Barcode graphic printing

4. 3 inch dot matrix printer

 Portable mini dot matrix printer SP-T5/ 3 inch dot matrix printer 1.Bluetooth,RS-232,IrDA interface option.
2.58mm paper width.
3.long battery life(7.4V, 1500mAh).
4.compatible with Android. Features: 1.Dot matrix impact printing method  2.Unique rugged design withstands drops up to 1.2 meter 3.Semi-auto paper loading   4.Large paper capacity and long battery life(7.4V, 1500mAh)   5.Intelligent quick charge battery   6.Continuing printing when battery in charging 7.Support a wide variety of serial and wireless communication options   Specifications:

Print	Printing Method	Dot Matrix
	Printing Speed	5.5mm/s, 1.2line/s(average)
	Resolution	5 dots/mm,240 dots/line
	Effective Printing Width	48mm
Character	Character Set	ASCII,GB18030(Chinese)
	Print Font	ANK: 7 x5/12 x6/16 x8, Chinese: 12 x 12/16 x 16
	Character per Line	12 x 12: 20( Chinese);40(English);16 x 16: 15( Chinese);30(English)
Paper Spec	Paper Type	Plain paper
	Paper Width	57.5± 0.5mm
	Paper Roll Diameter	Max:  40.0mm
	Roll Core Inner Diameter	13mm(min.)
	Paper Thickness	0.06 to 0.07mm
Paper Supply Method		Semi-auto loading
Reliability	MCBF	1,000,000 lines
	TPH	1,500,000 lines
Emulation		ESC/POS
Sensor		Paper End Sensor, Power Near End Sensor
Interface		T5-BT:RS-232, Bluetooth;  T5-Ir:RS-232, IrDA;
Power Adaptor		DC12V/2A
Battery Power		DC7.4V,1.5A rechargeable Li-ion battery
Battery duration		30m continuous printing (25%density)
Physical	Weight	270g(excluding roll paper)
	Dimension (WxLxH)	99 x 97 x46mm
	Color	Black
