Option GTM378 price of wifi module

Specifications The GTM378 is the second generation of PCI Express MiniCard module

Features
• Global connectivity with triple-band 3G and quad-band 2G
• Advanced Receiver Technology incorporating Receiver Diversity and Equalization
• High-speed data with HSDPA and UMTS (up to 7.2 Mbps downlink and 384 Kbps uplink) and backward compatible with EDGE / GPRS / GSM data connectivity (up to 247 Kbps)
• Transparent hand-over between UMTS and GSM / EDGE networks
• Low power dissipation for easy embedding into devices
• Benefits from large Option experience in PC datacards
• Easy integration made possible thanks to:
• Testing on infrastructures and networks worldwide
• Flexible driver design providing both NDIS and modem modes for easy integration into dashboard applications
• Future proofing through Flash Memory technology
• Connectors for external antennas   .Specifications
• HSDPA / UMTS
. Multi-bands variants (bands with Rx diversity are underlined)
› MO 0201: 850 / 1900 / 2100 ( Rx diversity) MHz
. Power Class 3 (+24 dBm)
. HSDPA modes:
› HSDPA 1.8: Categories 1-4, 11 and 12
› HSDPA 3.6: Categories 5 and 6
› HSDPA 7.2: Category 7 and 8 (SW upgrade)
. Equalization
. Rx diversity
. UMTS: 384 Kbps operation in downlink, 384 Kbps in uplink
. Support UL and DL Compressed Modes
. Circuit-switched data: 64, 14.4 and 9.6 Kbps   EDGE
. 850 / 900 / 1800 / 1900 MHz
. GSM Power Class 4 (2W) for 850 / 900 bands, GSM
. Power Class 1 (1W) for 1800 / 1900 bands
. EDGE class E2 (+27 dBm in 850 / 900 bands, +26 dBm in
1800 / 1900 bands)
. GPRS / EDGE Multislot Class 12 (4 slots Rx, 4 slots Tx)
. GPRS / EDGE Class B Type 1 MT
. GPRS CS1-CS4; EDGE MCS1-MCS9
. Circuit-switched data: 14.4 and 9.6 Kbps Not for IBM and some HP laptops
Item condition:Used,100% working
Unlocked World Work(Europe / Asia /Africa /Oceania)
