round chrome plating zinc cabinet door furniture cam lock

Specifications furniture cam lock

1.Model:SW-103 cam lock

2.IP41

3.round chrome plating zinc cabinet door cam lock

4.Operation Distance: 16

round chrome plating zinc cabinet door  furniture cam lock 1.Model:SW-103 cabinet lock 2.IP41 3.round chrome plating zinc cabinet door cam lock 4.Stopper length: 16,20,25,30mm.  5.Material and Surface Treatment: Housing and Insert : Zinc alloy die cast, bright chrome plated. Nut: Zinc alloy die cast,accessory with zinc plated. Key: Nickel-plating brass key with ABS handle. Cam: Cold rolled steel accessory with zinc plated. Insert-panel,Insert-hook: Brass, yellow. Spring, Key ring: Carbon steel wire, passivation. Steel Ball: Rolled steel accessory with bright chrome plated. Locking Screw: Rolled steel accessory with zinc plated...       1. Product's Brief

Item	furniture cam lock #Sw-103
Material	zinc-alloy
Surface treatment	bright chrome plating
Key	2 tubular keys for each lock
Master Key System	Available
Key Combination	Over 10,000
Operation Distance (X)	16/20/25/30mm
panel thickness	1mm-10mm
Applicability	Metal or nonmetal cabinet,network cabinet ,parking meter,distribution cabinet,meter boxes,electronic enclosures,panel box,controlling switch-board.
Website	www.sinwe.cn

2. Shipment & Payment

MOQ	500 PCS
Sample	Free sample,Freight amount should be paid by customer.
Lead time	10-25 days upon the order quantity.
Port of Loading	Shenzhen or other port as you request.
Payment terms	T/T, L/C, Paypal, West Union and etc.

3.Technical Drawing: 4.Plant View
