13.56MHz RFID S50 1K Contactless Card Factory Supply

Specification

Material

PVC

Antenna

Copper coil

Magnetic stripe Coercivity

650oe(JIS). 300oe(LoCo), 2750oe(HiCo)

Frequency

13.56Mhz,

Supported Standard

ISO14443A,

Chip Available

S50 1K

Protection Class

IP 68(condition : water pressure 45bar,10h)

Read Distance

within 20cm(this is dependent on antenna geometry)

Storage Temperature

-20 to 50’C

Operation Temperature

-20 to 50’C

Surface Finish

Gloss/Matt

Jis Magnetic stripe

Ext edge A 6.4mm(Max). Int edge B 11.6MM(Min)

Other Magnetic stripe

Coercivity(oersteds) 650oe;
Ext edge A 5.54mm(Max). Int edge C 15.8mm(Min);
Coercivity(oersteds)300oe(LoCo), 2750oe(Hico).

Size

Dimension

86*54*1.8mm, 86*54*0.8mm (±0.04mm)

Thickness

0.8mm/1.8mm

Product Description

1)   Customized Logo,color,figure

2)   The chip can be low frequency 125kHz , or high frequency 13.56MHz

Application

Door Access Control, Burglar Prevention, Patrol Management, Personal Identification,

Car Park Control, Member Club Management, etc
