Model

YCC-36CR

Power supply

V-Ph-Hz

220-240/1/50

Cooling

Capacity

Btu/h

36000

Input

W

4600

Rated current

A

21

Heating

Capacity

Btu/h

/

Input

W

/

Rated current

A

/

Indoor fan motor

Model

YDK90-6E

Input

W

143/114/93

Capacitor

μF

3.5μF/450V

Speed(hi/mi/lo)

r/min

770/640/550

Indoor coil

a. Number of rows

2

b. Tube pitch(a)× row pitch(b)

mm

21×13.37

c. Fin spacing

mm

1.45

d. Fin type (code)

Hydrophilic aluminium

e. Tube outside dia. and type

mm

7

Innergroove tube

f. Coil length × height × width

mm

1959.4×252×26.74

g. Number of circuits

12

Indoor air flow (Hi/Mi/Lo)

m3/h

1530/1300/1120

Indoor noise level (Hi/Mi/Lo)

dB(A)

44/42.5//41

Indoor unit

Dimension (W×H×D)

Body(mm)

840×300×840

Panel(mm)

950×950×55

Packing   (W×H×D)

Body(mm)

955×317×955

Panel(mm)

1035×1035×90

Net/Gross weight

Body (Kg)

35/42

Panel (Kg)

6/9

Refrigerant type

R22

Refrigerant piping

Liquid side/ Gas side

mm

12.7/19

Connection wiring

Power wiring

mm2

3.5

Signal wiring

mm2

2.5

Controller

R05/BGE

Operation temp

°C

17~30

Application area

m2

42-70
