4 output hd lnb/twin lnb super hd SR-6604 mini 4-output LNB for Satellite dish tv lnb hd

4 output hd lnb/twin lnb super hd SR-6604 mini 4-output LNB for Satellite dish tv lnb hd

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

4 output hd lnb/twin lnb super hd SR-3604 mini 4-output LNB for Satellite dish tv receiver Super HD sat SR-4604 4out put LNB
Quad LNB
KU BAND
Good quality MINI LNB KU BAND:

Input Frequency	10.7~12.75GHz
L.O.Frequency	9.75/10.6GHz±1MHz
Stability	±2MHz(-40°C~70°C)
L.O.Phase Noise	-70dBc/Hz@1KHz
	-90dBc/Hz@10KHz
	-110dBc/Hz@100KHz
Output Frequency	950~2150MHz
Conversion Gain	60dB(TYP)
Gain Flatness	±0.5dB/6MHz; ±2.5dB/In Band
Noise Figure	0.3dB(TYP)
Input V.S.W.R	2.5:1
Output V.S.W.R	2.5:1
Image Rejection	50dB(TYP)
Output Power	+5dB(MIN)(AT 1dB Compression)
Cross Polarisation	23dB(MIN)
DC Supply Voltage	11~14.5V(V), 15.5~22V(H)
Supply Current	130mA(MAX)
Low/High Band Switching	Low Band:0KHz
Low/High Band Switching	High Band: 22KHz±4KHz
Outpur Connecter	75Ω, "F" female
Operating Temperature	-40°C~+70°C
Relative Humidity	0%~95%
