PWM 1.5KW Off Grid Solar Power System Of Pure Sine Wave

100~230Vac PWM 3KW Off Grid Solar Inverter Of Pure Sine Wave Output For Solar System, off grid inverter, generator 3kw output, 3KW solar inverter, power inverter, Transformer protection solar power inverter.   1.CE certification
2.pure sine wave
3.Transformer protection
4.100~230Vac 50/60Hz PWM / MPPT off grid system
5. solar/city power priority

Model/Rated capacity(W)		XPI-1.5kva (1000w)
AC Input	Voltage range	100/110/120/127/220/230V(±20%)
PV Input	Max. Voltage (Voc)	50VDC
AC Output	Voltage range	100/110/120/127/220/230V(±5%)
	Transfer time	Typical: 5ms(Including detecting time)
Battery	DC Voltage	24V DC
General Data
Input	Frequency(Hz)	60/50±10%
Output	Wave form	Pure sine wave
	Frequency(Hz)	Commercial power supply: shared frequency with the commercial inversion. state:60/50±0.5
Protection	Overload	IPS automatically shutdown if overload exceeds 120% normal rating for 10 seconds, IPS automatically resume to work if overload comes to rated load.
Battery	Type	Sealed, maintenance-free lead acid.
	Recharge current	15A(Maximum)
	Battery protection	Automatic self-test, discharge protection, over-charged protection, smart management system.

  X- powerR Off Grid Solar Power System    XPI-0.5KVA~XPI-7.0KVA  ---- Pure sine wave output.   ---- With top quality IGBT tube. ---- LED displays for monitoring various parameters. ---- Over load, short-circuit, over voltage, low voltage and over heating protection. ---- Intelligent battery management with protection against over-charged &over discharged. ---- Superior performance with CPU control technology and low-frequency transformer isolation. can support with TV, Refrigerator, Fan, Microwave oven, Air condition etc. ---- Special protection for over load, automatically performs in protection status while it is over loaded, automatically restarts while recovers, automatically start-up while electricity available. ---- With Maintenance free Valve Regulated Lead Acid battery, protection for over charge and over discharge of   bttery for extending battery life.   Working Principle: Images:
