JFY SPRING Series 2.2 kw Solar Pump Inverter 3 Phase for 2.2kw Water Pump

Product Details JFY SPRING Series Solar Pump Inverter  Solar Pumping System uses the solar power which is one of green energy and it drives the pump directly after the
conversion of the inverter.The system requires no external battery, stores waters instead of electricity and then drives the AC pump. The system is economical, saving-energy and clean. It can be applied to many occasions such as people and animals drinking water in remote areas, farmland irrigation, desertification control and city landscape water use etc.
 SPRING series Solar Pumping Inverter from JFY company is dedicated to Solar Pumping System and it can be used for various application scenario. The Solar Pumping Inverter controls and regulates the system operation,converts the DC power from PV array to AC power and then drives AC pumps. It can adjust the output  frequency real-time according to the irradiation change and fulfill maximum power point tracking(MPPT).
Product Features
 Designed dedicated for solar pump, and compatible with various motor types; have excellent performance;
 IP 65 protection level, inverter integrates the combiner box which contains the PV dedicated DC switch, SPD, fuse  and other optional accessories;
 Natural cooling design, IP65 high protection level guarantees inverter to be applied under all kinds of outdoor strict environment;
 Using advanced dynamic VI MPPT technique ; fast respond and good operating stability;
 Main circuit adopts intelligent power module, high reliability, conversion efficiency reach to 98%;
 Advanced IGBT module, the high and low water position detection control circuit optional;
 Full automatic running; no need manual duty; the pump speed range can be set freely according to the system conditions so that guarantee the running time as long as possible;
 The inverter outer casing is solid and durable, compact size, nice appearance; friendly UI, user can check the real time info and historical info via the LCD display located in the front board; can store the running data up to 8 years;
 Plenty of communication interfaces, such as RS485/CAN/GPRS(optional); the running and status can be checked remotely;
 Inverter has perfect running protection mechanism, such as output short-circuit protection, IGBT over-current protection, input over/under voltage protection, overload protection, module overtemp protection, grounding protection and so on;
 Inverter allows using grid or diesel generator as backup power supply, 24-hour
Product Introduction Product Parameters

Model（SPRING）	750SL	750SLA	1100SL	1100SLA	1500SL	1500SLA	2200SL	2200SLA
Max PV Input Power(Wp)	1100	1100	1500	1500	2200	2200	3300	3300
Max DC Input Voltage(Vdc)	450
MPPT Range(Vdc)	150-400				200-400		280-400
Input String Number	1
MPPT Number	1
Max DC Input Current(A)	7		9		10		11
Rated Output Power(W)	750		1100		1500		2200
Max Output Current(A)	6.3		8.6		10		14
Output AC Voltage(V)	220V / Single phase
Matched Pump Voltage Range (Vac)	200-240V
Matched Pump Frequency Range (Hz)	0-50/60Hz
Max Conversion Efficiency	97.8%
MPPT Efficiency	99.9%
Operating Temperature(℃)	-25~+60
Noise[dB(A)]	<50dB
Night Consumption(W)	0
If Electrical Isolated	Transformerless
Cooling Type	Natural
Protection Level	IP65
Communication Type	RS485/CAN/GPRS
Dimension(W×D×H)mm	405*297*107
Weight(kg)	8				10
