JFY 3.3KW EVC series On-vehicle Charger for Evs

JFY 3.3KW EVC series On-vehicle Charger for Evs Product Description Product Features APFC≥0.99; LLC resonant frequency regulation, low standby power and high conversion efficiency; Having the control and guidance function to connect with the charging pile; Automatic switching between constant power and constant voltage, saving time for charging effectively; Having the CAN wake-up function; High-speed CAN communication bus, convenient for real-time detection and monitoring; With all protective functions; Technical data

	EVC 332420A	EVC 662450A
Input Voltage	85~264VAC
Rate Input Voltage	220VAC
Input Frequency	45Hz~65Hz
Input Power Factor	≥0.99(Rated input,Rated output)
Input Current	16A Max	32A Max
Peak Efficiency	≥93%(Rated input,Rated output)
Output Voltage	200~420VDC	200~450VDC(can be customized)
Output Current	10A Max	20A Max
Output Power	3.3kW Max	6.6kW Max
Voltage accuracy	±1%
Current accuracy	±3%(>5A)
Operating Temperature	-40~+60℃
Storage Temperature	-40~+90℃
Relative Humidity	5%~95%, No condensing
Communication Interface	CAN
Level of protection	IP66
Way of cooling	Forced air cooling
Weight	≤8.5kg	≤14.5kg
Protection Function	Output overvoltage/undervoltage, output overvoltage/undervoltage, overcurrent, short circuit, overtemperature, battery polarity reverse and other protective functions
Dimension((W*D*H)	293*200*147.5 mm	480*242*147.5 mm
