3528 PLCC2 Green SMD LED with 540nm to 550nm Wavelength for Sensor Applications

3528 PLCC2 Green SMD LED with 540nm to 550nm Wavelength for Sensor Applications

$2.00

10-1999 piece
$1.00

2000-9999 piece
$0.85

10000-49999 piece
$0.75

≥50000 piece

Min. Order:: 1 piece

Min. Order:: 1 piece

Port:: Shenzhen or Hongkong

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Supply Ability:	1000000 Piece/Pieces per Quarter
Payment Type:	Western Union,T/T
Port:	Shenzhen or Hongkong

Product Description

Special wavelength LED manufacturer hot sell 3528 PLCC2 540nm 545nm 550nm Green SMD Led lamp as sensor with ROHS

Shenzhen Starsealand Opto Electronic Co.,LTD deal with special wavelength LEDs from 250nm to 4400nm, if you have any inquires please let me know .

3528 PLCC2 540nm 545nm 550nm Green SMD Led as sensor

Product Description

Absolute Maximum Rating (Ta=25°C)

Item	Symbol	Value	Unit
DC forward current	I_F	20	mA
Pulse forward current	I_FP	100	mA
Power dissipation	P_D	60	mW
Operating temperature	T_opr	-20~+75	°C
Storage temperature	Y_stg	-30~+	°C
Reverse voltage	V_R	5	V
Sold soldering temperature	T_sol	260°C/3Sec	---

Plus with Max 10ms, duty ratio max1/10

Initial Electrical/Optical Characteristics (Ta=25°C)

Item	Symbol	condition	Min	Type	Max	Unit
DC forward Voltage	V_F	I=20mA	2.4	----	2.8	V
DC reverse Current	I_R	V=5V	----	----	10	μA
Chromaticity coordinates*	λ	I=20mA	545	----	550	nm
Spectrum Radiation Bandwidth	Δλ	I=20mA	----	28	----	Nm
Luminous Intensity	I_V	I=20mA	800	----	1200	MCD
50%Power Angle	2θ1/2	I=20mA	----	120	----	deg

Appearance

3528 PLCC2 540nm 545nm 550nm Green SMD Led as sensor

Size drawing

3528 PLCC2 540nm 545nm 550nm Green SMD Led as sensor
