Split Cooling/Heating Air Conditioner New Products 2014 HIG-C-005



"B1" Series
Model			9000BTU	12000BTU	18000BTU	24000BTU	30000BTU
			9K	12K	18K	24K	30K
			0.75Ton	1Ton	1.5Ton	2Ton	2.5Ton
Factory Model		Cooling	KF-25GW/B1	KF-35GW/B1	KF-50GW/B1	KF-70GW/B1	KF-90GW/B1
		Cooling&Heating	KFR-25GW/ B1	KFR-35GW/ B1	KFR-50GW/ B1	KFR-70GW/ B1	KFR-90GW/ B1
Optional Power Supply		Ph-V-Hz	1Ph 220V-240V/50Hz   0r 1Ph 208V-230V/60Hz
Cooling	Capacity	w	2500	3500	5000	7000	9000
	power	w	890	1270	1850	2500	3250
	Current	A	4	5.8	8.4	11.4	14.7
Heating	Capacity	w	2550	3600	5050	7100	9050
	power	w	880	1280	1800	2450	3230
	Current	A	4	5.8	8.2	11	14.7
Operation temp		°C	16-32	16-32	16-32	16-32	16-32
Ambient temp		°C	-7-45	-7-45	-7-45	-7-45	-7-45
Noise- indoor/outdoor		dB(A)	36/50	38/52	39/53	42/61	45/63
Weight- indoor/outdoor		Kg	9/28	10/32	14/42	17/50	25/65
Indoor Dimension	Net	mm	718*240*180	770*240*180	900*280*202	1033*313*202	1033*313*202
	Package	mm	805*305*225	855*305*255	985*365*298	1103*300*400	1103*300*400
Outdoor Dimension	Net	mm	640*240*490	760*260*540	760*260*540	810*285*640	865*310*680
	Package	mm	720*310*550	720*310*550	860*340*600	910*390*710	1040*410*790
Qty ’ per 20’ /40'HQ		set	135/350	120/265	110/230	70/170	60/145
Note:All the data in the brochure is only for reference,designs and specifications might be changed without prior notice.

     Products :             Our advantage
1.We have factory in China mainland.
2.We will have many new styles , and we can customized follow your design.
3.we have the factory ,can visit the factory at any time .
4.We can control the quality of products.
5.All of our products pass the certificate(CE or Rohs)
6.Our products “high efficiency” “energy saving” “environmental”.
7.We have our own factory, we are advantage at high quality with good price.   Our service 1.We would reply you soon as we can within 24hours. 2.We would follow your orders and inform you status at least every 2 days! 3.After your orders ,our sales would follow the shippping till to you received it. 4.We would send you information about our new products or promotional activity. 5.we would offer professional advice to install after your purchased.
  Payment and return policy
1.For the payment, we accept West Union, bank transfer, money gram, ESCROW.
2.If the total amount is more than USD1500 , 30% deposite first, rest 70% before shipment pay. If less than USD1500,please kindly make the 100% payment in advance.
3.After received the goods, please check the goods packing, if the packing is unseal or damaged on the shipping way. If yes please take the picture or make a video to us, after we see it we would resolve it.      More information welcome to contact us ! sales 1 Skype: ken.jia72 Sales 2 Skpe :fan.carmen 1 https://higv.en.alibaba.com  https://www.haiwei-group.com
