Industrial OEM Box PC Atom D525 1.8G with GM3150 Chipset

Specifications $keywords$

Intel Atom D525 1.8GHz Dual Core ,Fanless

WIFI(Optional),2xRJ45,4xUSB,6xCOM

$keywords$   Products View             Specification

Model	PC-GS525F
CPU	Intel D525 1.8GHz Dual Core
Chipset	Intel D525 + ICH8
Memory	Max. 4G
Graphics	Intel GM3150
Audio	Integrated AL C662 Audio
LAN	2xRTL 8111D, 10/100/1000M
Storage	supports standard SSD/2.5'HDD/Mini-SATA SSD
BIOS	AMI BIOS 4/8 Mbit flash
Back Panel Connector	1xVGR; 2xRJ45; 4xUSB; 6xCOM; WIFI(optional); 12V DC Power Input
Front Panel Connector	2xUSB; Power Button; Mic In/Audio Out
Operating System	Windowx XP/7, Linux, Win CE
Operating Temperature	0°c~50°c
Size	210x200x65mm
Material	High strength aluminum alloy chassis
Color	Black
Stucture	Fanless

      Installation   Desktop/Settop/Wallmount/Dinmount                                                    Packaging One Set/One Carton Carton Size : 340x260x120mm Net Weight :  3kg Gross Weight: 4kg Carton and foam packaging are all customized according to products dimension which provide protection of cargo to great extend during shipment.   Accessories  Driver Disk / Lockable Adapter / Power Cord / Internal Inspection Approval   Warranty  One year limited warranty   Testing Equipment  Part of testing equipment ( temperature&humidity&vibration combined testing machine/EMC device/ network performance analyis system/oscilloscope)           Advantage -Alluminium alloy chassis with radiation fin protects system from erosion  while providing high heat dissipation;   -Unique heat tower , made from material with low thermal resistance value,  efficiently conduct heat arising from  CPU to chassis which is turned to a  big heatsink by this thermal design;   -Fanless design, no CPU fan/system fan/power fan inside, greatly reduce  maintenance workload, also make it  possbile to work in dust-rich enviroment;   -Onboard CPU ensure protection against shock and vibration(complying IEC 60068-2-27/64);   -Reliability MTBF≥50000H;MTTR≤0.5H   -Compact structure and small size,suitable for installation in limited space.    Application Industrial Box PC is widely used in various system(automotive electronics/railsway traffic/vending machine/kiosk...)and mainly used as central control unit.        Application Demo(automotive)       Application Demo(AFC system)       Geshem Brief       Certificate CE / FCC/ Rohs ...
