Lechance OCAR street light warm white IP65 SMD5730 LED moddule

  Lechance OCAR street light warm white IP65 SMD5730   LED moddule  Features SMD LED Module Features: 1. With TOP 5730 SMD LED, no dark spot. very bright and uniform color.   2. With a low power consumption and high lumen value,40-45LM/led,a long life-span, maintenance free.   3. Plastic injection technique for outer cover, this design structure offer good heat transfer.   4. Saving energy 70% than traditional neon,and more bright.   5. IP Rate: IP65   6. Reliable and safe with DC 12V low voltage input   7. Viewing angle: 160-170°   8. 3 years warranty   9.Certified: CE ,ROHS,FCC   More Details Product application SMD LED Module Application:   LED module is perfect for back lighting glowing character, advertisement board, light box etc.   Technical parameters SMD LED Module Specification:

Product name	5730 SMD LED Module	5730 SMD LED Module
Model no	CR-MD-5730-3	CR-MD-5730-4
LED qty	3pcs SMD 5730	4pcs SMD 5730
Materials	White ABS	White ABS
Working Voltage	12VDC	12VDC
Consumption power	1.2watt	2.2watt
Color	Red,yellow,blue,green,white	Red,yellow,blue,green,white
Product dimension	66*17.5*6.5mm	37*37*7.5mm
Waterproof rate	IP65	IP65
Lumen	70-85lm	120-140lm
Working temperature	-20℃ —— +60℃	-20℃ —— +60℃
Storage temperature	-50℃ —— +60℃	-50℃ —— +60℃
Lifespan	50,000hrs	50,000hrs
Certified	CE ,ROHS,FCC	CE ,ROHS,FCC
