Mavic 3 Pro Drone Accessories ALIENTECH DUO II 2.4G/5.8G Dual-band Signal Booster Antenna Range Extender With Parts for DJI Dro

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	L/C,Western Union,D/A,T/T

Product Description

Mavic 3 Pro Drone Accessories ALIENTECH DUO II 2.4G/5.8G Dual-band Signal Booster Antenna Range Extender With Parts for DJI Drone

Product Description

Specifications

PARAMETERS

Product model: DUO-2458SSB

Dual-Band, Work with 2.4G and 5.8G

Working Frequency Band: 2400-24835 GHz / 5.725-5.850GHz

Working Voltage: 6-9V

Antenna Gain: 2.4G>13 dBi±1 / 5.8G>15dBi±1

Receive Gain: 10 dB±1

Transmit Gain: 15 dB±1

Input power range: 10-20 dBm

EVM: 3%@28 dBm 802.11G 54 Mbps OFDM 64QAM BW 20 MHz

Electric current:435 mA@POUT 28 dBm 9V

Noise coefficient: ≤ 2.5 dB

Transmission delay: ≤ 1 μs

Temperature: -40°C~80°C

Battery voltage and capacity: 3.7V 2800 mAh

Compatibility
Mavic 3 RC-N1

Mavic 3 RC Pro
