Multi-Beam Infrared Fence Sensor security system for home safe
- Delivery Time:
- 1 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong, China (Mainland) |
|---|
2.work with any alarm system
3.Can be all-weather outdoor use
Multi-Beam Infrared Fence Sensor security system for home safe DP-24 Description: 1. Use high-grade aluminum alloy shell, selection of components and the overall good stability, high reliability, strong anti-jamming capability.
2. Wired and wireless optional, suitable for different occasions, and can be compatible with our products or any brand alarm host.
3. All-weather outdoor use.
4. Tamper, shear, mobile, double beam recognition principle to prevent small animals, birds and other small objects cause false positives.
5.360 degrees stepless rotation, achieve rapid precise focus, unique terminals, convenient installation and debugging.
6. High sensitivity, vigilance to prevent from three gears is adjustable, AGC circuit design.
7. Easy to wiring, alignment or not have buzzer sound instructions.
8. To the company or any other similar type wireless learning brand, convenient installation. technical parameters:
Item /Technical Parameters / Type | Wide temperature active wireless infrared detector |
Infrared Distance | 100m |
Wireless Transmitting Distance | 100m |
Wireless Transmitting Frequency | FM: 433MHz |
Maximum alarm times in 24 hours | doorbell ringing times: ≤150; alarm times per minute: ≤9 |
Battery Capacity | 600mA (Transmitting Terminal), 1800mA (Receiving Terminal) |
Working environment temperature range | -30°C~70°C |
Number of infrared beams | 8 beams |
Operating Voltage | 3.3V |
Battery Type | LiFePO4 Battery |
Static Operating Current | transmitting terminal≤1mA, receiving terminal≤1mA |
Infrared light frequency | 38KHZ |
Infrared light wavelength | 940nm±20nm |
Solar electric panel output current | ≥8mA at an illumination level of 1800Lx (Note:The outdoor light intensity in cloudy or rainy days is about 2000LX |
