Plane 63*36mm Fresnel lens (pir sensor)
- Delivery Time:
- 5 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China (Mainland) |
|---|
Product Description
Product Description
Fresnel lens D7013 Fresnel lens arrays designed for Passive Infrared Sensor ,the optical surfaces are increases lens sensitivity for PIR sensor applications. Specification Overall size:63*36mm
Focal length: 22mm
Detectable distance: 10m
Viewing angle: 100° Color: Transparet Material: HDPE Shape: Plane Features:
Designed for passive infrared sensor applications
Well suited for compact, low profile sensors
Can be used in applications involving security, lighting controls and environmental controls
Optimized for dual element pyroelectric devices
White light immunity to reduce false triggers
UV resistant for outdoor applications
Designed for uniform sensitivity to reduce electronic gain
Focal length: 22mm
Detectable distance: 10m
Viewing angle: 100° Color: Transparet Material: HDPE Shape: Plane Features:
Designed for passive infrared sensor applications
Well suited for compact, low profile sensors
Can be used in applications involving security, lighting controls and environmental controls
Optimized for dual element pyroelectric devices
White light immunity to reduce false triggers
UV resistant for outdoor applications
Designed for uniform sensitivity to reduce electronic gain
