Leeman Group Grid-Tie solar power 50KW with grid tied inverter 10KW for commercial mounting system

  Monocrystalline Solar Panel 1)  MONO 125*125 105W 2)  MONO 125*125 140W 3)  MONO 125*125 155W 4)  MONO 125*125 160W-170W 5)  MONO 125*125 200W-210W 6)  MONO 125*125 260W-280W 7)  MONO 156*156 260W 8)  MONO 156*156 310W-320W     Polycrystalline Solar Panel 1)  POLY156*156 150W 2)  POLY156*156 220W 3)  POLY156*156 190W-200W 4)  POLY156*156 240W-250W 5)  POLY156*156 290W-300W 6)  POLY156*156 100W 7)  POLY156*156 120W     Quality and Safety 1. Rigorous quality control meets the highest international standards. 2. High-transmissivity low-iron tempered glass, strong aluminium frame. 3. Using UV-resistant silicon. 4. IS09001/14001/CE/TUV/UL     Warranties 1. 10 years limited product warranty 2. 15 years at 90% of the minimal rated power output 3. 25 years at 80% of the minimal rated power output     Productroduct Feature       1) High module conversion efficiency, through superior manufacturing technology.   2) Bypass diode minimizes the power drop by shade.   3) White tempered glass ,EVA resin,weather proof film and anodized aluminum frame to provide efficient protection from the severest environmental conditions.   4) Waterproof.Perfect for grid applications.   5) Solar panel guarantee 25 years performance.     Technical date :

ITEM NO.:	Mono 125*125 cell ,36pcs . Power range from 80Wp-110Wp
Maximum Power(W)	80	85	90	95	100	110
Optimum Power Voltage(Vmp)	17.81	17.89	17.94	17.99	18.06	22.20
Optimum Operatige Current(Imp)	4.78	4.91	5.12	5.35	5.59	4.955
Open Circuit Voltage(Voc)	21.98	22.05	22.14	22.28	22.45	26.5
Short Circuit Current(Isc)	4.95	5.15	5.36	5.65	5.84	5.462
Solar Cell:	125*125 Mono
Number of Cell(pcs)	4*9
Brand Name of Solar Cells	Leeman
Size of Module(mm)	1195*545*35
Cable & Connector Type	Pass the TUV Certificate
Frame(Material Corners,etc.)	Aluminium-alloy
Backing (Brand Type)	TPT
Cell Efficiency for 100W(%)	15.8%
Weight Per Piece(KG)	8.8KG
FF (%)	70-76%
Junction Box Type	Pass the TUV Certificate
Tolerance Wattage(e.g.+/-5%)	±3%, or 0-3%
Front Glass Thikness(mm)	3.2
Temperature Coefficients of Isc(%)	+0.04
Temperature Coefficients of Voc(%)	-0.38
Temperature Coefficients of Pm(%)	-0.47
Temperature Coefficients of Im(%)	+0.04
Temperature Coefficients of Vm(%)	-0.38
Temperature Range	-40°C to +85°C
Surface Maximum Load Capacity	2400Pa
Allowable Hail Load	23m/s ,7.53g
By pass Diode Rating(A)	12
Warranty	100% of 10 years
Standard Test Conditions	AM1.5   1000W/m2   25 +/-2°C
Packing	carton or pallet
1*20'	25 Pallets / 650pcs
1*40'STD	50 Pallets / 1300pcs

      More Solar Panel: Mono 10W/20W/30W/40W/50W/60W/70W/80-110W/130-160W/170W-210W/240-270W/270-310W  Poly 10W/20W/30W/40W/50W/60-70W/80W-110W/130-160W/230-260W/270-310W
