2013 Dayton High power IP65 Bridgelux led flood light 12w-220W,garden out door light led flood light

Specifications led flood light

1.Mean Well Driver led flood light

2.3 years led flood light

3.50000hours led flood light

4.CE RoHs

China IP65 Bridgelux leds,with Mean Well driver led flood light ,led floodlight,led light outdoor,flood light, led outdoor flood light    1.Parameter of the 180W led flood light, led floodlight,led light outdoor,flood light

Model	DT-F3931M-180W
Power Consumption	180W
Input Voltage	AC:90—300V 50-60HZ
Color Temperature	2800K-7000K, or customized
Luminosity	WW14380-15250LM  CW14580-15950LM
CRI	>75
Power Factor	>90%
LED Source	Bridgelux COB,Epistar
Size	397mm×310mm×187mm
Material	1060 pure aluminum buckle FAN process, fan heat, high-grade aluminum reflector cup, metal gusset plate, metal bracket, tempered glass, fully waterproof design(IP65).Product patents
Surface color	Black
Beam Angle	1200degree
Working Temperature	-30-- +50 degree
Waterproof Degree	IP65
Weight	8750g
Packaging Size	490×440×575mm   2pcs/caton
Packaging Weight	22.6/KG/2pcs
Certification	FCC CE RoHS
Warranty	3yrs

     Our all power flood light  details

Item Name	Input voltage(V)	LED quantity(Bridgelux)	Power(W)	Emitting color	Luminous Flux(lm)	Beam Angle	Dimension
DT-F1713H-12W	AC85-265V	10PCS	12	WW/NW/CW	WW780-920LM    CW830-1050 LM	120°	Φ179mm×133mm×57mm
DT-F2016H-20W	AC85-265V	20PCS	20	WW/NW/CW	WW1550-1750LM    CW1680-1820 LM	120°	Φ200mm×166mm×67mm
DT-F2016H-30W	AC85-265V	30PCS	30	WW/NW/CW	WW2080-2350LM    CW2380-2550 LM	120°	Φ200mm×166mm×77mm
DT-F2117H-50W	AC85-265V	50PCS	50	WW/NW/CW	WW3820-4180LM    CW4250-4550LM	120°	Φ215mm×178mm×81mm
DT-F2519H-70W	AC85-265V	70PCS	70	WW/NW/CW	WW4820-5560LM    CW4980-6150LM	120°	Φ253mm×194mm×95mm
DT-F2925H-100W	AC85-265V	100PCS	100	WW/NW/CW	WW7480-7960LM    CW8650-8550LM	120°	Φ291mm×250mm×116mm
DT-F3325H-130W	AC85-265V	130PCS	130	WW/NW/CW	WW9580-10850LM    CW9820-11250LM	120°	Φ330mm×250mm×192mm
DT-F3331H-150W	AC85-265V	150PCS	150	WW/NW/CW	WW11280-12360LM     CW11850-13580LM	120°	Φ337mm×310mm×187mm
DT-F3931H-180W	AC85-265V	180PCS	180	WW/NW/CW	WW14380-15250LM     CW14580-15950LM	120°	Φ397mm×310mm×187mm
DT-F4234H-220W	AC85-265V	220PCS	220	WW/NW/CW	WW16980-17550LM  CW17350-18860LM	120°	Φ422mm×340mm×121mm

    2.Sample photo of 180W led floodlight,led flood light,led floodlighting, led outdoor flood light     Some details about our led flood light, led floodlight,led light outdoor,flood light, led outdoor flood light   (1) Brideglux chips of the  our led flood light, led floodlight,led light outdoor,flood light, led outdoor flood light
     (2) the real pictures of our led flood light, led floodlight,led light outdoor,flood light, led outdoor flood light         Our led floodlight lighting in the water   Old style led floodlight     3.Specification and Packaging           4.Factory photo       5. led flood light manufacturing process :   6.Features of  our led flood light, led floodlight,led light outdoor,flood light, led outdoor flood light   1. Bridgelux chip integrated encapsulated high power LED ranges from 10-220W, which makes 80-90lm/W, with low lumens depreciation and good heat dissipation.

2. Aluminum alloy die-cast baking varnish heat sink, clear tempered glass, ensures good heat dissipation. IP65, Corrosion proof, Dust proof, Water proof, Shake proof.

3. Aluminum reflector designed after professional light distribution analysis, brings out the best light effect.

4. Being lighted up within 3 seconds with high CRI(color rendering index). Multiple-color for customers to choose: Red, Green, Blue, Yellow, White.   7.Application of the led flood light, led floodlight,led light outdoor,flood light, led outdoor flood light     8.Trade terms   1. Payment: T/T,Paypal, Western Union 2. Production lead time:5-7 days 3. Sample can be delivered in 3 days 4. Shipping freight are quoted under your requests 5. Shipping port: Shenzhen Mainland China 6. Discounts are offered based on other quantities 7.Private labeling and distributorships are offer under discussion.
8.Our own design and product development without any patent problem.
9.welcome you to visit our lighting showroom and factory.    9.Our service   1.Your inquirey related to our products or price will be replied within 24 hours 2.All your inquireies will be well explained by our experienced staff 3.OEM&ODM,also provide customized service 4.Distributorship is available for your unique design and some our current models 5.We will keep secret for customer sale area,design ideas and all other private information       More detailed information,please do not hesitate to inquiry now!It is my pleasure to service for you.   No Minimum order quantity limit,please contact me     email:tiffany(at)dtlighting.com   Skype:Tiffanyqinqin12
