LED Industrial High Bay Lighting 80 Watt

Specifications 80W LED High Bay

AC85-265V,80Watt,8000lumen

For replacement of 150Watt halogen lamps

indoor lighting,gym,warehouse,stadium

Bridgelux LED High Bay Light 80W   LED high bay 50W = HLP & MH 100W   LED high bay 80W = HLP & MH 150W   LED high bay 100W = HLP & MH 200W   LED high bay 120W = HLP & MH 250W   LED high bay 150W = HLP & MH 300W   LED high bay 200W = HLP & MH 400W        Introduction of parts of LED 80W LED high bay light     Feature:   1.External LED driver(Mean Well driver with UL list),top quality driver installed outside of the lamp,so the heat produced by the LED driver can be conduct into air directly,which helps excellent heat dissipation,long lifespan,easy for repair.   2.Rectangular fin shape pure aluminum heat sink, very big area for heat   dissipation,reduced 30% on heat than old type,while reduced 50% on weight.   3.3 separate unit of 50Watt COB high power LED(USA Bridglux) as the light source,it can light more area,high brightness,lower heat disspipation,longer lifespan.   4.PC reflector or Aluminum reflector for choice.   5.High bay and Low bay available.   6.Excellent heat dissipation, high brightness,long lifespan.   7.Light weight,save much cost on shipping.   8.Advantaged product price.   9.IP54 grade for indoor use.   10.Warranty:3 years     Specification of 80W LED high bay light:

Item No.	LS-HBX80X03(PC 90deg) / LS-HBX80X04(AL 120deg)/LS-LBX80X01(Low bay AL 120 deg)
LED type	COB high power LEDS 1 units
Input voltage	AC85-299V 50/60Hz
Chip brand	USA bridgelux
Power:	80W
Luminous flux	7200-8000 LM
Power factor	>0.95
LED luminous efficiency	90-100 LM/W
CRI	>75
LED Driver	Constant current
Circuit protection	Over-current & short-circuit & over-voltage & high voltage surges protection&IP66&CLASSII
Color temperature	2700-3500K (warm white)
	4500-5500K (pure white)
	>6500K (cool white)
Beam angle	90 deg &120deg.
Operating temperate	-40deg. to +60deg.
Lifetime	50000 hours
Material	FIN Al radiator+ Pure Al/PC reflector
Waterproof grade	IP54
Certificates	CE ROHS PSE UL
Warranty	3 years

      Dimension of 120W LED high bay light (unit: mm)   Low bay aluminum reflector 120 degree type     High bay aluminum reflector 120 degree type:   High Bay PC reflector 90 degree type:    Luminance distribution of 80W LED high bay light: Physical photo of LED high bay light ( 6000K ):       Installation of LED high bay lamp:               Packing information: Packing of Radiator: 1pc/carton, G.W: 3.5Kg/carton, Carton size: 29*29*25 cm   Packing of High bay reflector:   (PC 90deg) 10pcs/carton, G.W.: 9.8Kg/carton, Carton size: 43.5*43*61.5 cm               (Al. 120deg) 10pcs/carton, G.W.: 12.8Kg/carton, Carton size: 54*56*34.5cm       Application of LED high bay light:    Widely used in indoor supermarket, Chain store, warehouse, workshop, shops, factory, gym,stadium,exhibition hall etc.
