High resoulution and economic indoor rental LED display screen with light weight and IP65

Specifications 1, High resolution&refresh rate

2, light weight

3, Open-style case to make easy maintenance

4, front maintenance

High resoulution and economic indoor rental LED display screen with light weight and IP65   Overview An Series (indoor) is the light-weight and super-thin led display screens, which are very popular for video rental business and large square applications. Jointed correctly, easy to install and dismount. Simple structures are the main features of the screens. The unit size of the screen is 500mm*1000mm*65mm, while the weight is only 13kg/panel. An Series (indoor) are popular to install on entertainment areas, such as TV stages and clubs. The video performances of the An Series screens are brilliant, pretty clear, and real. An Series (indoor)is the best choice for creative designing company to achieve large square video show. Product Features:  l Light-weight. Convenient in transporting and installing saving labor cost, suitable for flow shows. l Nice appearance and simple structure.  l Jointed precisely, being installed &dismounted by one person without tool. l Humanized operating interface with breakdown indicator lights, easy to maintain. l High debugging brightness and no damage for nice image.    Technological Parameters

Item	An5	An6	An7	An8
Pixel Pitch	5.2mm	6.944mm	7.8125mm	8.92mm
LED type	RGB 3in1 SMD3230	RGB 3in1 SMD3528		RGB 3in1 SMD3535
Pixel Density(dot/s.q.m)	36864	20736	16384	12544
Resolution(WxH)	96x192 dot	72x144 dot	64x128 dot	56x112 dot
Cabinet size	500x1000x62mm			500x1000x68mm
Weight	10kg	10kg	10kg	13kg
Waterproof rate	IP43			IP65/IP43
Brightness	1300nits	1300nits	1300nits	4500nits
View Distance	6m	7m	8m	10m
Viewing Angle (H/V)	140°/120°
Gray Scale	14bit
Color type	68 Billion
Max.Power Consumption	250W/PCS	120W/PCS	120W/PCS	250W/PCS
Ave .Power Consumption	130W/PCS	60W/PCS	60W/PCS	130W/PCS
Refresh rate	1960Hz
Gamma	-5.0~+5.0
Applied environment	INDOOR			OUTDOOR
Controller	Synchronous display with control PC by DVI
Support Input	Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI
Power input	AC 220V±10%
Environment	temperature -10°C~+50°C,humidity 10~90% RH
Operating Life	50,000hours
