led display sign f s sign signled sign led screen p6 outdoor led screen P6 Indoor full color SMD LED module with high brightness

Specifications penalty shootout games led display screen

1.CE,ROHS,UL

2.Easy operation,Stable capability

3.3 years warranty

  Product Description   High resolution of indoor full color LED display; Integrated encapsulation is blessed with higher reliability; Good color mixture from far or very near distance; Good color consistency transparent picture; Good picture uniformity; Wide viewing angle; Higher contrast ratio; The most economical and rational solution for 3 in 1 full color technology.

Description	Technical parameter
	PCB			including LED board and Driver Board
	Module size			192×192mm
Unit	Pixel pitch			6mm
module	pixels Density			27777 dot each squarter  meter
	Pixel configuration			1R1G1B
	LED specification			(RGB)3528
	Pixel resolution			32 dots(W)*32 dots(H)
	Working Power consumption			9 W/module
	Max Power consumption			14 W/module
	Weight			0.38 kg
Power	Working voltage			DC5V
	Average Power consumption			190w each squarter meter
	Max. Power consumption			380w each squarter meter
	Current			≤20mA(single LED)
	CPU			Pentium 4 or above
	Operating system			WIN2000/NT/XP WIN7
Control	control method			Synchronization, Asynchronization
system	Driving device			Constant Current Driver IC
	Drive type			1/16 Scan
	Signal interface			HUB75
	Grey scale/colors			4096*4096*4096 colors
	View angle			110°(H) /55°(V)
	Brightness of white balance			≥1540cd each squater meter
Main	Brightness adjustment			256 levels of each color(R/G/B) by software
technical	Video Signal			PAL/NTSC
parameter	Control system			DVI display card + full color controller card
	MTBF			≥10,000 hours
	Life span			≥70,000 hours
	Flatness			Tolerance of interpixel≤0.3mm
				Tolerance of modules clearance ≤1.5mm
	Blind dots ratio			≤3PPM
	Communication distance			6~100 meters
	Operating Temperature			-20°C~60°C
	Operating Humidity			10%—90%RH


     Operating Principle                                                                                 Outdoor Display Effect:                                                                 Aging:       Applications:       Comercial advertising led display outdoor, Stadium perimeter led display outdoor,Mobile trailer led display outdoor module,  for mobile media,shopping mall led display outdoor for logo showing,bank&stock exchange led display outdoor for rates showing, train & bus   led display outdoor, air port led display outdoor, telecommunication led display outdoor system for information showing and instruction.       We offer you a possibility to run commercials on our screens which are unique advertising media that combine the advantages of outdoor and TV advertising. This kind of advertising is extremely important if you want to create and support one's company image or a product for the sales encouragement. There are many sizes for selection: outdoor, indoor display screens, semi outdoor screens. And also there are full color, dual color and single color for your selection. Customer's design size is acceptable.        LightIn Technology Ltd. is professional in the research and manufacturing of LED Display Screen, which is came into being and grew with the development of information technology. It’s well ahead of the LED display industry with the advantages of longer life span and high efficient of photoelectric conversion, etc. Meanwhile, it’s popular and widely used in daily life, such as finance, securities, stations, airports and supermarkets as the result of the digital-to-analog conversion; also it’s necessary for the live program in the stadium, especially for the direction in highway, that is significant to drivers; to the live show; parties and advertisement, it’s a visual revolution. All the examples show that LED Display is indispensable to wherever the life, work or entertainment.
      Packaging & Shipping       LED display outdoor Package:         LED display outdoor Installation:         FAQ       Trade Terms:   1.Payment: T/T , 35% deposits before production, 65% balance to be paid before dleiverying  (Western Union or paypal are welcomed)
2.Production lead time for 10~50pcs cabinet: 8-15 working days, 50~100pcs cabinet:25-35 working days
3.Sample can be delivered in 3days
4.Shipping freight are quoted under your requests
5.Shipping port: Shenzhen, Mainland China
6.Discounts are offered based on order quantities
7.MOQ:1pc           Our Services     Our service:   1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English .
3.OEM&ODM, any your customized screen we can help you to design and put into product.
4.Distributoer ship are offered for your unique design and some our current models .
5.Protection of your sales area, ideas of design and all your private information         LED display outdoor Factory:     ----------------------------------------------------------------------------------------------------       Welcome to visit our factory! (Shenzhen, China)   Contact: Dylan wang  Skype: nicolewang28 Mobile:+86 135 0285 4073
