Outdoor P16 Rental LED Display

Specifications Rental LED Display

1.High brightness>6000 nits

3.CE&RoHS &URL certificate

4.Vivid pictures

5.IP65 class protection

1. The specification of P16 outdoor Rental LED Display

Product Model	P16
Pixel Pitch	16 mm
Pixel Density	3906 Pixels/m²
Pixels Composition	2R+1G+1B
Module Resolution(H×V)	16 Pixels × 8 Pixels
Cabinet Resolution(H×V)	64 Pixels × 48 Pixels
Module Dimension(H×V)	256 mm × 128 mm
Cabinet Dimension(H×V)	1024 mm × 768 mm
Brightness	>6500 cd/m²
Optimal Viewing Distance	>16 m
Max. Power Consumption	900  W/m²
Scan Mode	Static, Constant Current
Viewing Angle	H <110, V <60
Refresh Frequency	300HZ~9600HZ(Depending on control system)
Inputting Voltage	220V or 110V
LED life span	50,000 - 100,000 H
Operating Temperature	-20°C~+60°C
Ingression Proof Grade	Front: IP65; Back: IP54;

  2. Advantage of P16 outdoor Rental LED Display     1).Large viewing angle with horizontal 160 degree and vertical 80 degree pictures do not distort and deviate at any angle within the scope 2).Imported chip with copper bracket, gold wire and silver paste, color brightness less than 5% after 1000 hours 3).Easy maintenance for front side and back side and quick assembly 4).Excellent R&D team with its professional for remote wireless control system
3. Advantage of TOPLED   Topled Co.,Ltd is a big factory in China. With skillful workers, it is experienced in manufacturing LED display. Established in 2004 400 emplpyees,Huge R&D team 12000 sqms plantarea Automatic machines ISO9001:2008 Quality control system 8 mins driving to shenzhen airport Huge R&D team Fast and better after-sales service   4. Module of P16  Rental LED Display 5. Package and Certificates      6. TOPLED Opto-electronic Technology CO.,LTD.
