Outdoor P31.25 DIP led curtain

Get Latest Price

Payment Type:: L/C, D/P, T/T

Min. Order:: 1 Square

Min. Order:: 1 Square

Delivery Time:: 2 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)
Supply Ability:	54000 Square Meter/Square Meters per Week
Payment Type:	L/C,D/P,T/T

Product Description

Specifications Outdoor P31.25 DIP led curtain

1)5500CD/M2

2)CE,RHOS,UL

3)Water proof IP65 front /IP54 back

4)Good after sale serces

Product line: Outdoor:P10/P12/P14/P16/P18/P20/P22/P25/P31.25/P50/P62.5 Indoor:P4/P5/P6/P7.62/P8/P10/P12 Curtain LED,Mesh LED,Video wall,Perimeter screen,Protable screen,and so on P31.25 DIP outdoor curtain led display

Cabinet	Item	Parameter
	Pitch (mm)	31.25mm
	Led	Silan
	LED Standard	2R2G2B (DIP546)
	Cabinet size	1000mm x 1000mm
	Cabinet resolution	32*32
	Drive Mode	Constant static
	Cabinet weight( kg)	24kg / cabinet
Display	Density (Real) (dots/m^2)	1024dots/ m2
	Display Color	16777216
	Gray Grade (Rank)	14bit
	Viewing angle	Horizontal 60,Vertical 120°
	Brightness Peak white	>5500cd/ m2
	Max Power Consumption (W/m^2)	450
	Avg. Power Consumption (W/m^2)	180
	Work Voltage	AC 220V/110V
	Refresh rate	≥560
	Control Mode	Synchrony Transfer
	Work environment	-20°C~+50°C
	Protection Level (IP)	IP65

Packing and Delivery term: plywood case/carton case/flight case delivery time:3-20days

SHENZHEN TOPLED OPTO-ELECTRONIC TECHNOLOGY CO.,LTD. 12000 Square meters Modern Factory Advanced Automatic Manufacturing Equipment Normative Producing Process and Rigid Quality Control System other related articles of outdoor &indoor led display and led lights are also available Should any questions , pls free to contact with me name : jodie mobile phone :13418976962 skype number :jodie901014 gtalk number :jodiemiao
