Diesel injector diagnostic ben ch HKCR-709 original common rail Bo sch fuel pump

HKCR-709 adopts full-automatic control, and can test hundreds of kinds of injector and high-pressure pump including BO SCH, SIEM ENS, DE LPHI, DE NSO, Cate rpillar etc. with complete experimental data.      Configuration

Main motor	Hengshui "Energetic OX", Shanghai "People" (11kw/15kw)
Converter	"Q MA", "L G", "SIE MENS", "L K"
Standard common rail fuel pump	Bos ch Original CP3 or CP1H
Standard fuel rail	Bos ch Original with DRV fuel rail
Low pressure hose	Korean APH heatresisting and high tensile oil tube
Injector sensor	Original import sensor
Pump sensor	Original import sensor
Display	Brand new HD 23 inch LED display
Industrial Motherboards	Industrial Intel Platform
Filter	Euro III Special Filter
Temperature Control System	Efficient and intelligent heating and cooling group

    Injector Test Equipped with Bo sch original imported CP3 pump and high-pressure fuel rail with DRV, can drive 6- cylinder solenoid valve and Piezoelectric injector, to carry out injector test under different working conditions   Can select number of injector cylinder to carry out automatic measurement cylinder by cylinder, test bench RPM, Automatic steering control, and automatic rail pressure regulation, maximum up to 2000Bar, can stabilize within 10Bar, and can measure oil amount and generates report automatically.     Fuel Pump Test   Can drive different kinds of high-pressure pumps like Bo sch CP1/CP2/CP3, De lphi CRSP, De so HP3/HP4, Siemens DCP and Denso HP0 pump.        Test bench RPM, Automatic steering control, Automatic rail pressure regulation, the maximum can reach 2000Bar,can stabilize within 10Bar, and can measure oil amount and generates report automatically.     Affiliated features   Unique in China   DRV clogging automatic warning function, will save a great amount of usage expenses for you.         Main Characteristics German Original Glow Sensor  Several High-precision Diesel Filters Automatic Data Generation   Self-R&D, Constant Updating & Promotion of Products      Technical Parameters

Working Voltage	AC380V
Output Power	11~15 KW
Rail Pressure Range	0~2000 Bar
Rail Pressure Control Accuracy	±0.5 MPa
Fuel Pump Rotation Speed	0 ~ 4000 RPM
Diesel Filter Accuracy	< 5 U
Injector Sensor Range	0.1 mL - 600 mL
Injector Sensor Accuracy	0.1%
Pump Sensor Range	10 mL - 3000 mL
Pump Sensor Accuracy	0.5 %
Dimension	218*78*140 cm
Net Weight	960 KG
