professional Common Rail Test Bench APEX-709 fuel injector cleaner

Common Rail Test Bench APEX-709 APE X-709 adopts full-automatic control, and can test hundreds of kinds of injector and high-pressure pump including BO SCH, SIE MENS, DELP HI, D ENSO, Cate rpillar etc. with complete experimental data.   Product Introduction APEX-709 adopts full-automatic control, and can perform maintenance test of Euro III, Euro IV, EuroV injector and high-pressure pump conveniently. It can test hundreds of kinds of injector and high-pressure pump including BO SCH, SIEM ENS, DE  lPHI, DENSO, Cater pillar etc. with complete experimental data. This test bench, integrated with original imported high-precision flow sensor, has functions: automatic measurement of oil quantity and automatic generation of fuel pump nozzle maintenance report etc..    Configuration

Main motor	Hengshui "Energetic OX", Shanghai "People" (11kw/15kw)
Converter	"Q MA", "L G ", "SIE MENS", "L K"
Standard common rail fuel pump	Bo sch Original CP3 or CP1H
Standard fuel rail	Bo sch Original with DRV fuel rail
Low pressure hose	Korean APH heatresisting and high tensile oil tube
Injector sensor	Original import sensor
Pump sensor	Original import sensor
Display	Brand new HD 23 inch LED display
Industrial Motherboards	Industrial Intel Platform
Filter	Euro III Special Filter
Temperature Control System	Efficient and intelligent heating and cooling group

  Product Features
As long as you fill in information, install a new injector and let it automatically works, it will create data well for you in half an hour. You can save the new injector test data for permanent use. Injector Test Equipped with Bosc h original imported CP3 pump and high-pressure fuel rail with DRV, can drive 6- cylinder solenoid valve and Piezoelectric injector, to carry out injector test under different working conditions Can select number of injector cylinder to carry out automatic measurement cylinder by cylinder, test bench RPM, Automatic steering control, and automatic rail pressure regulation, maximum up to 2000Bar, can stabilize within 10Bar, and can measure oil amount and generates report automatically. After comparing experimental data of hundreds of kinds of injectors, it can automatically judge the injector to be tested is good or not via reports. All injector drive channels have short circuit protection function. Fuel Pump Test Can drive different kinds of high-pressure pumps like Bos ch CP1/CP2/CP3, De lphi CRSP, De nso HP3/HP4, Siem ens DCP and Denso HP0 pump. Test ben ch RPM, Automatic steering control, Automatic rail pressure regulation, the maximum can reach 2000Bar,can stabilize within 10Bar, and can measure oil amount and generates report automatically. After comparing experimental data of hundreds of kinds of injectors, it can automatically judge the injector to be tested is good or not via reports. All high pressure pump drive channels have short circuit protection function. Technical Parameters

Working Voltage	AC380V
Output Power	11~15 KW
Rail Pressure Range	0~2000 Bar
Rail Pressure Control Accuracy	±0.5 MPa
Fuel Pump Rotation Speed	0 ~ 4000 RPM
Diesel Filter Accuracy	< 5 U
Injector Sensor Range	0.1 mL - 600 mL
Injector Sensor Accuracy	0.1%
Pump Sensor Range	10 mL - 3000 mL
Pump Sensor Accuracy	0.5 %
Dimension	198 * 84 * 150 ( cm )
Net Weight	680 KG

Affiliated features     Unique in China     DRV clogging automatic warning function, will save a great amount of usage expenses for you.   Main Characteristics  German Original Glow Sensor  The injector sensor, which is ellipsoid gear sensor, is of high precision and reveals fuel amount instantly. Thus it resolves the problems such as low speed, big error, incapable to measuring small volume and fragileness caused by using traditional weighing sensor;  Fuel pump sensor covers great measuring range. With a steel inner core, it is stable, durable and difficult to clog while running big flow of fuel.   Several High-precision Diesel Filters Given that test bench runs fuel circularly, and all the pump, DRV, fuel controlling valve and sensor are easy to clog, we install high-precision diesel filters to make sure it work stablely and long time, and more safer to use.
Automatic Data Generation As long as you fill in information, install a new injector and let it automatically works, it will create data well for you in half an hour. You can save the new injector test data for permanent use.
Self-R&D, Constant Updating & Promotion of Products   Being with powerful R&D team, we can assure consitant updating and promotion of our products, and developing more practical functions.  Can make personalized functions, including test bench appearance, color, precedure interface,  advertisement, etc.
Providing spare parts, maintenance guidance and whole set training services.  All investers of our company have run pump maintenance store over ten years. Experienced in this industry, we provide professional training & guidance and spare parts support to help you become real expert in pump & injector maintenance.     We have customers from countries below, and more:
