bus ac control panel with LED display Panel control Bus Air Conditioner controller

Electric Bus Air-conditioning Panel Controller
HKACP01 is one of the most Comprehensive bus ac Electric Control Device. This panel including function keys including automatic control, refrigeration, fresh air, self-test, power-down memory fault alarm display, indoor and outdoor temperature, multi-stage air volume adjustment, over-voltage automatic protection, and the second function etc.   Detailed function of each key in Panel

Front Cover Back Cover Radiator Grid Protective Film Buckle Air Volume Fault Diagnosis Fresh Air Fan Mode Manual Refrigeration Auto Refrigeration Power Screen Temperature Control

 bus ac control panel with LED display Technical Parameters   Temperature Range: 15-32°C Working Voltage: DC24V (DC20 +1 V ~ 32 +1 V)         Temperature and humidity range: -30 °C -80 °C, 5% -95% RH non-condensing environment Storage temperature and humidity range: -10 °C -70 °C, 5% -95% RH non-condensing environment   Input: 1) Return air temperature sensor (25 ° C, Rb = 5K, B = 3274); 2) Defrost temperature sensor (25 °C, Rb = 5K, B = 3274); 3) Pressure sensor; 4)Power (Generator Power Detection); 5) Auto power source (battery); 6) Backlight power;   Output: 1) Condenser fan (maximum 300mA);   2) High wind speed (maximum 300mA); 3) Wind Speed (maximum 300mA);      4) low speed wind (maximum 300mA); 5) Fresh Air open (maximum 300mA);   6) Fresh Air off (maximum 300mA); 7) Compressor clutch (maximum 300m A);  8) Excitation (maximum 3)   Connector instruction:

Pink	white	Green	Yellow green	Red white	Red black	Red	Brown
Fresh Air	Pressure	Defrost	Room temperature	Backlight	AC electricity	Auto electricity	Ground
Black			Purple	Gray red	Yellow	Blue	Gray
Ground			Refrigeration	Evaporation high	Evaporation middle	Evaporation low	Excitation

 bus ac control panel with LED display Features: 1. Long life's-pan working for bus AC.
2. All kinds of bus brand: Kia, DAEWOO , Hyundai , Kinglong bus, Yutong bus, Higer bus, Golden dragon bus, Jinbei car, Iveco car and so on. 3. Good price with a closer service. It is a durable products for bus air conditioning system Our bus AC control panel with an easy and simple mounting design. It provides Fan high, Fan middle, Fan low; Error display; Compressor indicating, shift function. Good price and service gives your all the business convenience.   We offer kinds of bus air conditioning control panel for your flexible choice.  Most items are all popular and universal mounting for your buses air conditioner.  Just let us know your special demands, we will give you all the information as soon as possible. You may interested other necessary AC parts to exchange this compressor, such as Clutch, Compressor, Generator,Refrigerant. More details please e-mail to www.densoautoac.com or call 8618679600390.
