7inch 4-Wire Resistive LCD Touch Screen with Controller

7inch 4-Wire Resistive LCD Touch Screen with Controller

Get Latest Price

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Info.

Model NO.

RG-RTP070-4Wire

Size

Resolution

800*480

Luminance

400

Contrast Ratio

500:1

Type

TFT

Feature

LED Backlight Display

Interface Type

VGA

Transport Package

Stardard

Specification

CE, RoHS, SGS

Trademark

Rongen

Origin

China

Production Capacity

15000/Month

Product Description

SPECIFICATION:

Size	7"
Constrcution	Glass, uniform resistive coating, polyester coversheet, transparent insulating dots, conductive coating
Operating Force	10g~100g
Chattering	≤12ms
Surface Hardness	Moths 3
Life Time	More than 1 million touches in one location without failure
Transparency	≥80%
Working Voltage	5.0V
Circuit grade	DC5V 1mA
Insulation impedance	≥20MΩ(25V DC)
Linearity	≤1.5%
Operating Temperature	-30°C to 80°C

Operating Temperature: -30~85
Storage Temperature: -30~85
Pixel Pitch: 0.1926x0.1790mm (WxH)
Weight: 150g(Typ. )
Surface: Antiglar
Active Area: 154.08x85.92mm (WxH)
Bezel Area: 156.7x89.1 mm(WxH)
Outline Dimension: 164.9x100mm (WxH)
Outline Depth: 5.7+-0.3mm (Typ. )
Touch Panel: Without TP
Response Time: 10/15(Typ. )(Tr/Td)
Viewing Angle: 70/70/50/70(Typ. )(CR>=10)(L/R/U/D)
Interface Type: FPC
Interface Pin Pitch: 0.5mm
Interface Pins: 50pins
Backlight: LED
