Product Description
Product Description:
Size : 7.0 inch
Colors : 256/65K color
Dots : 800 (RGB) *480 resolution
Layer: 256 color 800*480 resolution 2 layers
64K color 800*480 resolution 1 layers
Controller IC : RA8875
Data Bus: MCU 8-bit/16-bit 8080 or 4-wire SPI
CTP connecter: I2C
Temperature range :
Operation:-20 oC ---- +70oC
Storage:-30 oC ---- +80oC
Viewing size: 156.7x 89.1mm
Active area: 154.08 x 85.9mm
Outline dimension: 183.4x110.7 x 17.3mm Max.
Interface Discriptions:
External Dimensions:
