5 Inch 640X480 TFT LCD Display Industrial CTP Rg-Zj050na-08c-1
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Info.
Model NO.
RG-ZJ050NA-08C-1
Widescreen
Not Widescreen
Response Time
10ms
3D
Not 3D
Interface Type
Ttl
Resolution
640X480
Luminance
250 CD/M2
Contrast Ratio
500:1
Operating Temperature
-20~70
Storage Temperature
-30~80
Viewing Angle
70/70/50/70
Display Color
16.7m
Active Area
101.57X76.18 mm
Module Size
117.65X88.43X5.7 mm
Pins
50pin
Transport Package
Stardard
Specification
CE, RoHS, SGS
Trademark
Ronen
Origin
China
Production Capacity
15000PCS/Month
Product Description
General Specifications
RG-ZJ050NA-08C is a TFT-LCD module. It is composed of a TFT-LCD panel,
driver IC, FPC, a back light unit. The 5.0" display area contains 640x480 pixels and
can display up to 16.7M colors. This product accords with RoHS environmental
criterion.
No. Item Specification Remark
1 LCD size 5.0 inch(Diagonal)
2 Driver element a-Si TFT active matrix
3 Resolution 640 ×(RGB) × 480
4 Display mode Normally White, Transmissive
5 Dot pitch 0.053(W) × 0.159(H) mm
6 Active area 101.57(W) × 76.18(H) mm
7 Module size 117.65(W) × 88.43(H) × 5.70(D) mm Note 1
8 Surface treatment Anti-Glare
9 Color arrangement RGB-stripe
10 Interface Digital
11 Backlight Power consumption 0.960W (Typ.)
Merchanical Drawing
RG-ZJ050NA-08C is a TFT-LCD module. It is composed of a TFT-LCD panel,
driver IC, FPC, a back light unit. The 5.0" display area contains 640x480 pixels and
can display up to 16.7M colors. This product accords with RoHS environmental
criterion.
No. Item Specification Remark
1 LCD size 5.0 inch(Diagonal)
2 Driver element a-Si TFT active matrix
3 Resolution 640 ×(RGB) × 480
4 Display mode Normally White, Transmissive
5 Dot pitch 0.053(W) × 0.159(H) mm
6 Active area 101.57(W) × 76.18(H) mm
7 Module size 117.65(W) × 88.43(H) × 5.70(D) mm Note 1
8 Surface treatment Anti-Glare
9 Color arrangement RGB-stripe
10 Interface Digital
11 Backlight Power consumption 0.960W (Typ.)
Merchanical Drawing
Our LCD module size are from 2.8 inch to 10.1 inch which are widely used in digital camera, DV, security monitoring, carcorder, PMP, MID and Education Learning Aid, POS Machine etc.
| Product | Application |
| Small-size TFT LCD display | mobile device,watch,toy,medical equipment, Office electronic equipment,camera, air-condition display, etc. |
| Mid-size TFT LCD display | mobile device,medical equipment,car, automotive product,industrial control equipment,POS,PDA, Household Video doorbell, air-condition display,etc. |
| Big-size TFT LCD display | educational product,automotive product,video door phone, Audiovisual equipment,DVD player,media play,tablet PC, Security Products,etc. |
| TN/STN//FSTN/OLED | elevator controller,watch,electronic product,air-condition display,all kinds of instrument,etc. |
| Plastic mould | industrial control equipment,electronic product,toy, Security Product,IT digital product, sports equipment,etc. |
