Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD
  • Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD
  • Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD
  • Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD
  • Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD
Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD
Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD
Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD
Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD

Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD

Get Latest Price
Min. Order:
1 Piece/Pieces
Min. Order:
1 Piece/Pieces
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Product Description
Product Description

Basic Info.

Model NO.
RG215XXS-01
Widescreen
Widescreen
Response Time
8ms
3D
Not 3D
Interface Type
2-CH Lvds
Input Terminals
30 Pins
Resolotion
1920*1080
Luminance
200 CD/M2
Contrast Ratio
3000:1
Active Area
476.64 (H) * 268.11 (V) mm
Outline Size
495.6 * 292.2 * 10.62 mm
Operation Temperature
0 ~ 50
Storage Temperature
-20~60
Viewing Angle
88/88/88/88
Transport Package
Stardard
Specification
CE, RoHS, SGS
Trademark
Rongen
Origin
China
HS Code
9013803020
Production Capacity
10, 000/Month

Product Description

Specification:
Item  Specification
Module Size  495.6(H) X 292.2 (V) X 10.62 D) mm
Display area  476.64 (H) x 268.11 (V) , (21.5" diagonal) mm
Bezel Opening Area  479.8(H)x271.3(V) mm
Number of Pixel  1920 x R.G.B. x 1080 Pixels
Pixel pitch  0.24825 (H) x 0.24825 (V) mm
Pixel arrangement  RGB Vertical Stripe
Display color  16.7M
Transmissive Mode  Normally BLACK
Surface treatment  Anti glare(Haze 25%), Hard-Coating(3H)
Electrical Interface  2-ch LVDS
Optimum viewing direction  +80/-80(H),+80/-70(V) Typ.(CR≥10)

Features:
  1. High contrast ratio, high aperture structure
  2. High speed response
  3. FHD (1366 x 768 pixels) resolution
  4. White LED Edge slim Backlight (1-side)
  5. DE (Data Enable) only mode
  6. LVDS (Low Voltage Differential Signaling) interface (2pixel/clock)
  7. RoHS, Halogen Free
  8. It is recommended to support in system level )
Applications:
  1. Workstation &desktop monitors
  2. Display terminals for AV application products
  3. Monitors for industrial machine

Ronen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCDRonen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCDRonen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCDRonen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCDRonen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCDRonen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCDRonen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCDRonen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCDRonen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCDRonen Rg215xxs-01 Terminals for AV Application Medical Instruments Display 21.5 Inch 1920*1080 LCD
