2.6 Inch 16*2 Resolution Stn LCD Module for Coffee Machine
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
Your message must be between 20 to 2000 characters
Contact NowBasic Info.
Product Description
| Screen size | 2.6"(Diagonal) |
| Display color | Display color:Black |
| Background color | Yellow Green |
| Type | STN |
| View angle direction | 6'clock |
| Driver mode | 1/64 DUTY 1/9 BIAS |
| Backlight | LED |
| Controller IC | 7066/7065 |
| Data bus | 8 bit |
| Operation | -20 oC ---- +70oC |
| Storage:-30 oC ---- +80oC | -30 oC ---- +80oC |
| Number of Dots | 16*2 |
| Dot size | 0.54*0.52mm |
| Dot pitch | 0.64*0.62mm |
| Viewing size | 64.3*16.3mm |
| Active area | 55.46*10.76mm |
| Outline dimension | 90.0*31.0*9.6mm Max. |
Outline drawing
Applications
Our LCD module size are from 2.8 inch to 10.1 inch which are widely used in digital camera, DV, security monitoring, carcorder, PMP, MID and Education Learning Aid, POS Machine etc.
Product |
high luminance 9 inch tft lcd module 9 tft lcd screen 9 tft lcd |
Small-size TFT LCD display |
mobile device,watch,toy,medical equipment, Office electronic equipment,camera, air-condition display, etc. |
Mid-size TFT LCD display |
mobile device,medical equipment,car, automotive product,industrial control equipment,POS,PDA, Household Video doorbell, air-condition display,etc. |
Big-size TFT LCD display |
educational product,automotive product,video door phone, Audiovisual equipment,DVD player,media play,tablet PC, Security Products,etc. |
TN/STN//FSTN/OLED |
elevator controller,watch,electronic product,air-condition display,all kinds of instrument,etc. |
Plastic mould |
industrial control equipment,electronic product,toy, Security Product,IT digital product, sports equipment,etc. |
