DWDM / CWDM 10G Media Converter Copper To Fiber , RJ45 To SFP+
MAIN APPLICATIONS
- Connection between fiber to copper 10Gbps Ethernet equipment function as fiber-to-copper media converter for long distance transmission
- Media converter for network backbone(SAN, LAN, MAN)
- Can be applied in Telecommunication room, R&D laboratory, Data center, and etc.
KEY Feature:
- Support Jumbo Frame
- Transparent Transport and very low delay
- Support ITUT prescribed DWDM/CWDM wavelength
- Support DMI function for SFP+ fiber module
- Support Loopback test function
- Economic In-band Management function
- powerful Network Management function(Web,SNMP,Console)
- Support hot plugging
- Support 2U Rack (16 channel) and standalone use
- Full State Led display
- Easy installation
- UTP cable length detection(only RJ45 interface)
Technical Information:
|
Performance Data |
Technical Indexes |
|
Transmission Speed |
10Gb/s |
|
Protocols |
IEEE802.3an(10Gbase-T),IEEE802.3ae(10Gbase-SR/LR/ER/ZR) |
|
Access Type |
10G LAN |
|
Interface Type |
Type: RJ45 To/From SFP+ |
|
Transmission Distance |
SFP+ module: Up to 80Km 10Gbase-T: 100meters Cat .6a cable |
|
Maximum Packet Forwarding Rate |
14,880,950/S |
|
Network management information: |
• Card type information • SFP+ fiber module detection • SFP+ fiber module DMI function ( Temperature , Voltage , Optical power ) • Link status detector • Enable/Disabled Loopback test function • UTP cable length detection ( only RJ45 interface ) • Remote card's status monitor ( only in pairs ) |
|
power requirement |
Rack-mountable : AC 85 ~ 220V OR DC -48V Standalone: AC 220V OR DC -48V Power consumption: ≤9W |
|
Work Environment |
Operating Temp: 0~ 50 ℃ Storage Temp: -10~ 70 ℃ Humidity: 5%~90% ( non-condensing ) |
|
Dimension |
Card : 11.5mm ( W ) × 78mm ( D ) Standalone : 156mm ( W ) × 128mm ( D ) × 32mm ( H ) |
