CE Approved Water To Water Heat Pump For House Heating Cool

Model No.

MG-300-SFXRS

Metal Plate

SGCC/Spray Gray

Unit Size(W*D*H)

2000*1120*900

Compressor

Copeland

Refrigerator

R407C

Voltage

380V/50Hz

Condenser

Double-pipe φ273

162-φ9.52*1800

Evaperator

Double-pipe φ273

162-φ9.52*1800

Thermostatic Expansion Valve

Danfoss

AC Contactor

(220V-50A)*2

Thermal Relay

(24-36A)*2

Controller

DF1SS-TS5 System

Motoro1a IC

Low Pressure Switch

0.15/0.32MPa

High Pressure Switch

3.0/3.6MPa

Wire Insert Unit

3*16mm²+2*6mm²

Package

Plywood CTN

Heating Capacity(kW)

115

Heating Input Power(kW)

23.9

Rated Current(A)

62

COP

4.81

Rated Water Temp.Output(℃)

55

Max Water Temp.(℃)

60

Hot Water Capacity(L/H)

2471.94

Size of Hot Water Pipe(mm)

DN65

Temp.of Water In(℃)

15

Temp. Water Source Outlet(℃)

10

Water Source Cycling Capacity(m³/H)

34.5

Size of Water Source Pipe(mm)

DN65

Level of protection

IPX4

Electric Shock Proof

I

Noise(dB(A))

≤70

N.W./G.W.(kg)

650/700
