Low Noise All In One Air Source Heat Pump For Hot Water Coe

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China

Product Description

3 KW All In One Air Source Heat Pump For Hot Water With Low Noise And High COP

Specifications:

Model			KF30-150
Standard Configuration	Metel plate		Unitary plastic mold
	Body size(φD*H)		φ510*1660
	Compressor		Toshiba
	Refrigerant		R417a/1150g
	Power supply		220V/50Hz
	Evaporator		3(D44)-W395*H380
			φ7 internal thread /20U tube
	Filter net	W415*H375
	Four-way valve		SHF-4-23U-P
	Motor (with capacitance)		YDK12-4H-3
	Fan		φ300*79
	Electronic expansion valve		1.65C-10
	High-voltage switch		2.4/3.0MPa
Parameters	heating capacity(kW)		3
	input power(kW)		0.865
	Rated current (A)		3.9
	COP		3.47
	rated outlet water temperature(℃)		55
	Highest outlet water temperature(℃)		60
	Water tank volume(L)		150
	Water tank rated working pressure(Mpa)		0.7
	IP Grade (Level of protection)		IPX4
	Anti-electric shock Rate		I
	Noise (dB(A))		≤48
	Net weight(kg)		62
	Gross weight(kg)		70
	Pipe size(mm)		DN12

Application:

Business Organizations	supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations	Banks, negotiable securities, funds, insurance companies, pawnshops; Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places	subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;
Entertainments	Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course
