3 KW Heating Capacity All In One Air Source Heat Pump For S

Model

KF30-150

Standard Configuration

Metel plate

Unitary plastic mold

Body size(φD*H)

φ510*1660

Compressor

Toshiba

Refrigerant

R417a/1150g

Power supply

220V/50Hz

Evaporator

3(D44)-W395*H380

φ7 internal thread /20U tube

Filter net

W415*H375

Four-way valve

SHF-4-23U-P

Motor (with capacitance)

YDK12-4H-3

Fan

φ300*79

Electronic expansion valve

1.65C-10

High-voltage switch

2.4/3.0MPa

Parameters

heating capacity(kW)

3

input power(kW)

0.865

Rated current (A)

3.9

COP

3.47

rated outlet water temperature(℃)

55

Highest outlet water temperature(℃)

60

Water tank volume(L)

150

Water tank rated working pressure(Mpa)

0.7

IP Grade (Level of protection)

IPX4

Anti-electric shock Rate

I

Noise (dB(A))

≤48

Net weight(kg)

62

Gross weight(kg)

70

Pipe size(mm)

DN12
