7500 CD PH10 Outdoor LED Display Screen Rental Video proces

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China

Product Description

MBI5024 IC PH10 Outdoor LED Screen Rental with 1/4 Scan Constant Current

Quick Detail:

1. Video processor applied;

2. All Epistar LED;

3. 1R1G1B;

4. 10,000 pixels / sq.m;

5. MBI5024 drive IC;

6. 2 years quality guarantee.

Detail Description:

Rental LED display screen is made of aluminum case, light, easy to assemble and disassemble;

Working temperature could be as low to -40℃;

Hanging beam or other equipments could be offered together.

Application:

Installed on public for some important events.

Specifications:

Type	P10
Pixel Composition	1R1G1B
LED Type	DIP346
Pixel	10,000 dots/sq.m
LED Module Pixel	W 16 × H 16
LED Module Size	W 160 × H 160 mm
Normal Cabinet Dimension	W 960 × H 960 mm
Cabinet Color	Black
Cabinet Material	Aluminum made
Driving Mode	1/4 scan constant current
Brightness	≥7500 CD/sq.m
Refresh Rate	≥1200Hz
Out of Control Dot Rate	＜0.0001
Earth Leakage Current	＜2mA
MTBF	＞5,000 hours
LED Life	＞100,000 hours
Power Supply	110V/60HZ and 220V/50HZ interchangeable
Humidity	10%~90%
Control Method	Synchronous control with PC on
Input Signal	DVI, COMPOSITE VIDEO, S-VIDEO, HDMI

Outdoor LED Rental Screen, Aluminum Outdoor LED Screen Rental, Outdoor LED Screen Rental for Events
