Epistar PH6 1R1G1B Indoor Full Color LED Display 27777 dots
  • Epistar PH6 1R1G1B Indoor Full Color LED Display 27777 dots
Epistar PH6 1R1G1B Indoor Full Color LED Display 27777 dots

Epistar PH6 1R1G1B Indoor Full Color LED Display 27777 dots

Min. Order:
1
Min. Order:
1
Delivery Time:
30 Days
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: China
Product Description
Product Description

PH6 1R1G1B Indoor Full Color LED Display with 3000 CD Brightness

Quick Detail:

1. Epistar LED chip;

2. 1/8 scan constant current;

3. About 1,000 W/sq.m biggest consumption;

4. 2 years quality guarantee;

5. Chuanglian CE power supply;

6. Nova controller.

Detail Description:

Surface mounted device (SMD) is mature now;

Auto-brightness setting could be made via multifunctional card;

Reserve parts provided based on purchasing quantity.

Specifications:

Model

P6

LED Composition

1R1G1B

LED Type

SMD3528

Pixel

27,777 dots/sq.m

LED Module Pixel

W 32 × H 16

LED Module Size

W 192 × H 96 mm

Standard Cabinet Size

W 960 × H 768 mm

Box Color

Black

Box Material

Steel

Driving Mode

1/8 scan constant current

Luminance

≥3000 nits/sq.m

Refresh Rate

≥800Hz

Out of Control Dot Rate

<0.0001

Earth Leakage Current

<2mA

MTBF

>5,000 hours

LED Life

>100,000 hours

Power Supply

110V/60HZ and 220V/50HZ interchangeable

Humidity

10%~90%

Work Temperature

-20~+60℃

Operation System

Win2000 / XP / Vista

6mm Indoor Full Color LED Display, Indoor Full Color LED Display Board, Indoor Full Color LED Advertising Display
