Basic Info

Place of Origin:	Shenzhen, China

Product Description

Quick Detail:

1. Billboard advertising super brightness, waterproof IP65

2. 48bit colors processing

3. Energy saving, easy maintenance

4. Advanced dot adjusting

5. CE,ROHS,UL,ISO,FCC

6.Long Lifespan > 100,000 hours

P12 Outdoor Advertising LED Display , IP65 LED Display Panel

Description:

1. Super brightness and color uniformity and reproduction. Brightness variances within+/-2.5%

2. High reliability: data hot backup aims to avoid any communication risks during the show; support

automatic fault detection

3. Refresh rate is up to 4,200Hz, completely flickering-free for live video

4. Proprietary image processing produces sharp, brilliant images unmatched by industry competition

5. 2000: 1 contrast ratio tempers screen brightness into sharp, focused images whether up close or far

away

6. 8000 nits guarantees the screen stays brighter longer, providing 100,000 hours of continuous use

Applications:

Ideal for dazzling different events, such as Stage, Concert, Fashion Show, Wedding, Conference, Building,

Hotel, Club & Bars, Festival, etc.

Specifications:

1. Outdoor LED Display Technical Parameter

Model No.	NS-OR-DD-P12
Pixel Pitch	12mm
Module Size	192 mm ×192mm
Module Resolution(Pixel)	16 dots×16dots
Pixel Density	6944 dots/m2
LED Type	3mm Oval Lamp
Pixel Configuration	1R1G1B
Wavelength (R.G.B)	R:625±2nm G:525±2nm B:470±2nm
Drive Mode	Dynamic 1/4 Duty Constant Current
Cabinet Size	1152×768×150mm
Cabinet Resolution	96dots×64dots
Brightness	≥6000 cd/m2
Contrast	≥2000:1
Viewing Angle	110°(Horizontal )/45°(Vertical )
Best Viewing Distance	10~300 m
Grey Scale	10bits/1024levels
Color Capability	16777216
Color Temperature	5000-9300K
Maximum Power Consumption	1000 W/m2
Average Power Consumption	350W/m2
Working Voltage	AC220V/110V s±15% 50-60 HZ
Frame Frequency	≥60HZ
Refresh Frequency	≥240HZ
Brightness Correction	Pixel, Module, Cabinet Correction
Operating Temperature	Static:-40°C ~ +85°C Working:-20°C ~ +60°C
Operating Humidity	10-90% RH
LED Lifespan	100,000 hours
MTBF	≥50000 hours
Computer Operation System	Win 98/ Win XP/ Win 2000
Video Signal Input	RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite
Video Signal Output	RF, S-Video, GB, RGBHV, YUV, YC etc.
Graphics Card	DVI Graphics Card
Control Distance	UTP CAT5E:100m Multi-mode Fiber:500m Single-mode Fiber:10km
Control System	LINSN OR DB-STAR
Software	LED studio 10.0
Waterproof Level	IP65(front side), IP54 (back side)
Installation	Wall mount, hung and stand structure
Out of Control Rate	0.01 %

2. Outdoor LED Display Module

3. Outdoor LED Display Cabinet
