SJ Series Single Screw Extruder PPR Pipe Production Line High Efficiency Extruder
Quick Detail of PPR pipe production line extruder :
1.pipe single screw extruders
2. plastic extruder
3. single screw pipe extruder
4. mainly used to process PP, PE PPR
Description of PPR pipe production line extruder :
SJ Single Screw Extruder is mainly used to process PP, PE, PP-R,ABS and other plastics. Equipped with auxiliary machines, it can manufacture profile, pipes, sheets and other plastic products and granulation. It has the advantage of simple production technological process, high output, stable quality and low cost.
Applications of PPR pipe production line extruder :
1.Suitable for various polyolefin materials: HDPE, PPR, PP,and ABSetc. Adopt advanced human-machine interface control system to realize the automatic control of the whole line.
2.Excellent temperature control system to ensure the stability of the producing process. Integrated design of force water cooling and force feeding groove ensures the evenness and stability of the manufacturing process.
3.High-performance driving system; Wearable and easy to maintain.
Specifications of PPR pipe production line extruder :
| Model | L/D | Output | Speed of Screw Rotationl | Power | Center Height |
| SJ-30 | 10-33 | 10-25kg/h | 20-120r/min | 3-5.5kw | 1000mm |
| SJ-45 | 10-33 | 10-35kg/h | 20-120r/min | 7.5-18.5kw | 1000mm |
| SJ-50 | 10-33 | 20-80kg/h | 20-120r/min | 22-37kw | 1000mm |
| SJ-65 | 10-33 | 80-150kg/h | 20-120r/min | 37-55kw | 1000mm |
| SJ-75 | 10-33 | 120-280kg/h | 20-120r/min | 55-90kw | 1000mm |
| SJ-90 | 10-33 | 150-450kg/h | 20-120r/min | 90-160kw | 1200mm |
| SJ-120 | 10-33 | 300-600kg/h | 20-120r/min | 160-260kw | 1200mm |
| SJ-150 | 10-33 | 450-700kg/h | 20-120r/min | 260-315kw | 1200mm |
Competitive Advantage of PPR pipe production line extruder :
This series high efficiency single screw extruder to introduce the Europe advanced concept of plastic extruding ,screw use L/D 38:1 .
Double mixing head, separation structure,can make sure melting material 100% plasticizing before die head,capacity increases by about 30% than in ordinary domestic models;it is used for PE/PPR/PPB/PPH/PERT and PB.
To meet of the individual demand and more diverse applications,our company can supply different L/D extrusion machine.
