HGK-80 Conventional welding rotator for boiler welding in E

80T Conventional Welding Rotator made in China (EUROP Standard)

1. Specifications:

Specification and type: HGK-80
Max load weight: 80T
Work scope: ￠850-5000mm
Diameter and width of the wheel: ￠500*120mm
Wheel linear velocity: 0.1-1m/min
Power of motor: 4kw
Way of setting: screw adjust or bolt adjust

2. Applications:

3. Competitive Advantage:

Automatic welding machine such as welding rotator mainly includes the power rotator, idler rotator, electrical control parts.

The power welding rotator by two wheel device can rotate a certain angle, the base, reducer and motor worm gear worm reducer. The welding rotator use tuning speed motor driven, by a worm gear drive worm reducer drive two worms gear worm reducer to rotate the rotator, the friction on both sides when the work-piece rotates balanced distribution of play smooth and drive to increase the work-piece rotation effect on the quality of the work-piece processing play a strong guarantee. Such a structure than the two-motor drive wheel is more stable, easier to synchronize. The rubber wheels on both sides of the respective installed metal wheel, rubber wheel protection, and the corresponding carrying a work-piece load to improve the friction of great help to ensure that long use of rubber wheel. As can be rotated a certain angle, so with the size of the work-piece specifications can automatically adjust to ensure the work-piece rotates smooth, continuous self-adjusting roller wheel device. Reducer lubrication with oil-immersed fully enclosed to eliminate weld spatter, slag, dirt and dust and debris, resulting in maintenance-free and long life characteristics. By more than thoughtful consideration to ensure that the device can adapt to a variety of environmental requirements, to ensure that the work-piece quality and efficiency of protection.
