IR Sensor 304 Stainless Steel Drop Arm Barrier Bi-direction
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|
Swift Lane Drop Arm Gate turnstile Door Access Controller for Pedestrian Entrance
Stainless steel smart control system high technology security barrier automatic gate drop arm turnstile
product name: drop arm gate turnstile
Quick Detail:
| Brand Name | RS Security | Modle Number: | RS 1009B | Material: | 304 stainless steel |
| Size: | 1200x165x990mm | Finished: | Brushed surface | Power supply voltage | 220V AC220±10% |
| Weight | 102kg/unit | Guarantee: | 2 years | Place of Origin: | China(shenzhen) |
Description:
- The barrier arm turnstile is a perfect combination of aesthetic look and fast passage.
- Normal close or normal open can be switched.
- It provides standard or wide lane to meet different requirements for the lane width, the lane width can be 600-1200mm
| Features |
| Bidirectional control, by authorized card or biometric identifications, push button and so on |
| Can be integrated with all kinds of access control systems, |
| Flow direction guide with high bright led lamp |
| Anti-punch, the barrier will not close if it detects people inside the passageway |
| Anti-tailgating, it allows only one person to pass for an authorized card presented. |
| Anti-panic, when power off, the barrier will open for people to go through. |
| Normal close or normal open (for group pass) |
| Close and open by remote control |
| Card reading memory function, the user can set multiple time card reading passing or single time card reading passing |
| Failure detection and alarm functions; |
| Optional features |
| Case size changes. |
| Telescopic arm color, material to customize. |
| Counter displays. |
| Sound and light alarm. |
| Voice prompt. |
| Infrared number increase or decrease. |
| Other possible increase or decrease, change parts requirements |
| Applications: |
| Office building, factory, fitness club, prison, hotel lobby, school, port, exhibition hall. |
Traffic type
Specification
|
Material |
304 stainless steel |
Input voltage |
220V AC220±10% |
|
Size |
1200x165x990mm |
Arm length |
300-600mm |
|
Net weight |
102kg/unit |
Clear passageway |
600-1200mm |
|
Motor |
24V DC brush |
Top Cover |
Acrylic or stainless steel |
|
Communication interface |
RS485 |
Sensor beams |
5 pairs for 1 complete lane |
|
Transit speed |
30-40 people/minute |
Service life |
3000,000 times |
|
Close and open time |
0.6S |
Input interface |
Relay signal, 12V level signal, |
|
Clear passage width |
600mm-1200mm |
Work environment |
Indoor and outdoor (shelter) |
|
Number of led lamp |
3pcs |
Model |
RS1009 |
Competitive Advantage:
- We are a leading manufacturer of turnstile and speed gate in China.
- We focus on pedestrian turnstile gates.
- We keep stock for regular products and we can support small orders. Usually, our lead time is just 3 days.
- Design products according to customers’ requirements.
- Credibility: We are SGS certificated Supplier. Our customers are located over 50 countries
- Gratitude: We cherish the business chance you give us and return you with quality products and good service.
- Professional: We have been in this business for more than 8 years. We have a strong professional team with various experiences.
- We keep doing new product development. Our goal is to enhance our competitive capacity constantly.
- Price: very competitive price and good quality products
- Quality: we do 100% inspection before the shipment.
- Promise: we are always ready to take the responsibility if any loss caused to our customer due to our mistakes.
